Watlow Series 988 Family - Manual (Page 72)

A.2
Data Communications with the Watlow Series 988 Family Appendix
ASCII Ctrl Key Definition Dec. Hex.
Char. Equiv. Equiv. Equiv.
ENQ Ctrl E Enquiry 5 05
ACK Ctrl F Acknowledge 6 06
NAK Ctrl U Neg. Acknowledge 21 15
STX Ctrl B Start of Text 2 02
ETX Ctrl C End of Text 3 03
EOT Ctrl D End of Transmission 4 04
DLE Ctrl P Data Link Escape 16 10
CR Ctrl M Carriage Return 13 0D
DC1 Ctrl Q XON 17 11
DC3 Ctrl S XOFF 19 13
Dec Hex Char Dec Hex Char Dec Hex Char Dec Hex Char
00 00 NUL 16 10 DLE 32 20 SP 48 30 0
01 01 SOH 17 11 DC1 33 21 ! 49 31 1
02 02 STX 18 12 DC2 34 22 " 50 32 2
03 03 ETX 19 13 DC3 35 23 # 51 33 3
04 04 EOT 20 14 DC4 36 24 $ 52 34 4
05 05 ENQ 21 15 NAK 37 25 % 53 35 5
06 06 ACK 22 16 SYN 38 26 & 54 36 6
07 07 BEL 23 17 ETB 39 27 ' 55 37 7
08 08 BS 24 18 CAN 40 28 ( 56 38 8
09 09 HT 25 19 EM 41 29 ) 57 39 9
10 0A LF 26 1A SUB 42 2A * 58 3A :
11 0B VT 27 1B ESC 43 2B + 59 3B ;
12 0C FF 28 1C FS 44 2C , 60 3C <
13 0D CR 29 1D GS 45 2D - 61 3D =
14 0E SO 30 1E RS 46 2E . 62 3E >
15 0F SI 31 1F US 47 2F / 63 3F ?
Dec Hex Char Dec Hex Char Dec Hex Char Dec Hex Char
64 40 @ 80 50 P 96 60 ` 112 70 p
65 41 A 81 51 Q 97 61 a 113 71 q
66 42 B 82 52 R 98 62 b 114 72 r
67 43 C 83 53 S 99 63 c 115 98 s
68 44 D 84 54 T 100 64 d 116 74 t
69 45 E 85 55 U 101 65 e 117 75 u
70 46 F 86 56 V 102 66 f 118 76 v
71 47 G 87 57 W 103 67 g 119 77 w
72 48 H 88 58 X 104 68 h 120 78 x
73 49 I 89 59 Y 105 69 i 121 79 y
74 4A J 90 5A Z 106 6A j 122 7A z
75 4B K 91 5B [ 107 6B k 123 7B {
76 4C L 92 5C \ 108 6C l 124 7C |
77 4D M 93 5D ] 109 6D m 125 7D }
78 4E N 94 5E ^ 110 6E n 126 7E ~
79 4F O 95 5F _ 111 6F o 127 7F DEL
ASCII Character Set
ASCII Control Characters (Partial Set)
Table A.2b -
ASCII Control
Characters
(Partial Set).
Table A.2a -
ASCII Character Set.
ASCII
