Page 37

Name

Description

Read (?) and/or Write (=) Syntax

Range

data.1

data.2

Modbus

Address

Ramping Controller Prompt Table

981,

982,

983, 984

Command Summary Series 981-984, Chapter 5

Data Communications with the Watlow Series 988 Family

5.9

OTY1

Output 1 Hardware

0 = None

16
OTY2

Output 2 Hardware

1 = SSR 0.5A

17
OTY3

Output 3 Hardware

2 = SSR 0.5A with suppression

18
OTY4

Output 4 Hardware

5 = Dual SSR form A

6 = Switched dc
7 = Dual switched dc
8 = Relay 5A form C
9 = Relay 5A form C with suppression
10 = Relay 5A form A/B
11 = Relay 5A form A/B with suppr.
12 = Dual Relay form A
13 = Process output
14 = Voltage retransmit
15 = Current retransmit
16 = Power supply
17 = Comms EIA-232
18 = Comms EIA-485 / EIA-422
19 = Comms EIA-485 / EIA-232

PB1

Proportional Band

? PB1

if DFL = 0 and CF = 1, then 0 to 555°C

500

Output 1

= PB1 data.2

if DFL = 0 and CF = 0, then 0 to 999°F
if DFL = 0 and In1 = a process value,
then 0 to 999 units
if DFL = 1, then 0.0 to 99.9% of span
Default: 25°F, 14°C, 25 units, or 3.0%

PB2

Proportional Band

? PB2

if DFL = 0 and CF = 1, then 0 to 555°C

510

Output 2

= PB2 data.2

if DFL = 0 and CF = 0, then 0 to 999°F
if DFL = 0 and In1 = a process value,
then 0 to 999 units
if DFL = 1, then 0.0 to 99.9% of span
Default: 25°F, 14°C, 25 units, or 3.0%

POUT Power Outage

? POUT

0 = Continue

1206

Response

= POUT data.2

1 = Hold (HOLD)
2 = Abort
3 = Idle set point (IDSP)
4 = Reset

PRC1

Process Range

? PRC1

0 = 4-20mA

701

Output 1

= PRC1 data.2

1 = 0-20mA
2 = 0-5V
3 = 1-5V

(dc)

4 = 0-10V

(dc)

Default: 0

PRC2

Process Range

? PRC2

0 = 4-20mA

718

Output 2

= PRC2 data.2

1 = 0-20mA
2 = 0-5V

(dc)

3 = 1-5V

(dc)

4 = 0-10V

(dc)

Default: 0

PRC3

Process Range

? PRC3

0 = 4-20mA

735

Output 3

= PRC3 data.2

1 = 0-20mA
2 = 0-5V

(dc)

3 = 1-5V

(dc)

4 = 0-10V

(dc)

Default: 0

PSTR

Program Start Point

? PSTR

0 = Start @ current process value

1207

= PSTR data.2

1 = Start @ hold mode set point
Default: 1

Table 5.9 -

OTY1 to PSTR

CAUTION:
Avoid writing <=>
continuously, such
as ramping set
points or repetitive
loops, to the
Series 981-984
EEPROM memory.
Continuous writes
may result in
premature control
failure, system
downtime and
damage to pro-
cesses and
equipment.

NOTE:
The number of
decimal places
returned by many
of these com-
mands is deter-
mined by the DEC1
or IN1 setting.
(This does not
apply to Modbus
Protocol.)
