Ramping controller prompt table, Table 5.3, A2hi to amb – Watlow Series 988 Family User Manual
Page 31

Name
Description
Read (?) and/or Write (=) Syntax
Range
data.1
data.2
Modbus
Address
Ramping Controller Prompt Table
981,
982,
983, 984
Command Summary Series 981-984, Chapter 5
Data Communications with the Watlow Series 988 Family
5.3
Command Summary Series 981-984 Data Communications
Name
Description
Read (?) and/or Write (=) Syntax
Range
data.1
data.2
Modbus
Address
A2HI
Output 2 Alarm High ?
Process: A2LO to sensor high range
322
=
Deviation: 0 to 9999°
Rate: 0 to 9999°/minute
Default: RH, 999°, or 999°/min.
A2LO
Output 2 Alarm Low ?
Process: sensor low range to A2HI
321
=
Deviation: -999 to 0°
Rate: -999 to 0°/minute
Default: RL, -999°, or -999°/min.
A3HI
Output 3 Alarm High ?
Process: A3LO to sensor high range
341
=
Deviation: 0 to 9999°
Rate: 0 to 9999°/minute
Default: RH, 999°, or 999°/min.
A3LO
Output 3 Alarm Low ?
Process: sensor low range to A3HI
340
=
Deviation: -999 to 0°
Rate: -999 to 0°/minute
Default: RL, -999°, or -999°/min.
ABSP Abort Set Point
?
off
1211
=
RL to RH
ACAL Calibration Offset for ?
-999°F to 999°F
746
Retransmit Output
=
-555°C to 555°C
999 to 999 units
Default: 0°F, 0°C, or 0 units
AL2
Alarm 2 Type
?
0 = Process Alarm, Input 1
719
=
1 = Deviation Alarm, Input 1
2 = Rate Alarm, Input 1
Default: 0
AL3
Alarm 3 Type
?
0 = Process Alarm, Input 1
736
=
1 = Deviation Alarm, Input 1
2 = Rate Alarm, Input 1
Default: 0
ALM
Alarm Status
?
0 = No alarms occurring (0000 0000)
106
(Writing a 0 clears
=
Bit 1 = A2LO
(0000 0001)
or
next alarm.)
Bit 2 = A2HI
(0000 0010)
110
Bit 3 = A3LO
(0000 0100)
Bit 4 = A3HI
(0000 1000)
106 = Alarm 2
0 = off
1 = HI
2 = LO
110 = Alarm 3
0 = off
1 = HI
2 = LO
AMB
Ambient Terminal
?
Input 1 terminals in 0.0°F
1500
Temperature
Table 5.3 -
A2HI to AMB
ç
CAUTION:
Avoid writing <=>
continuously, such
as ramping set
points or repetitive
loops, to the
Series 981-984
EEPROM memory.
Continuous writes
may result in
premature control
failure, system
downtime and
damage to pro-
cesses and
equipment.
NOTE:
The number of
decimal places
returned by many
of these com-
mands is deter-
mined by the DEC1
or IN1 setting.
(This does not
apply to Modbus
Protocol.)
