WATLOW Series 965 User's Manual 39 Appendix
Output 1
C = Switched dc output, non-isolated
D = Electromechanical relay, Form C, 5A, without contact suppression
1 3
F = Process, 4-20mA Î (dc), non-isolated
K = Solid-state relay, Form A, 0.5A, without contact suppression
3
Output 2
A = None
C = Switched dc output, non-isolated
D = Electromechanical relay, Form C, 5A, without contact suppression
1 3
K = Solid-state relay, Form A, 0.5A, without contact suppression
3
Line Voltage/Power
0 = 100-240V~ (ac) nominal (high voltage)
1 = 12-24V~ (ac) nominal or 12-24V
Î (dc) (low voltage)
Display
Upper Display Lower Display
00 = Red Red
RG = Red Green
GR = Green Red
GG = Green Green
Model No.
Series 965 Model Number Information
Ordering Information—W965-XMNN Rev A00
9 6 5 A - 3 _ _ _ - 0 0 _ _
* Note: If this output will drive a solenoid, MDR,
contactor or other inductive device, order a
Quencharc™ (0804-0147-0000) for output
protection. See Chapter 2 for wiring.
Spare Parts
• Mounting collar
0822-0395-0000
• Case gasket 0830-0402-0002
• Protective terminal cover 0822-0426-0001
• Internal bezel gasket 0830-0402-0001
• Quencharc™ RC 0804-0147-0000
suppressor
