Series 142
Series 142
Line
Voltage Input Temp Range Control Mode Action Output Set Point Mounting Retrofit
See Notes
Below
142A-3716-2200 230 VAC K t/c 122°F High limit Manual Reset 3A Relay Fixed Potted LF E4KU 0122 AAAA A 6, 8
142A-3716-2200 230 VAC K t/c 50°C High limit Manual Reset 3A Relay Fixed Potted LF E4LU 0050 AAAA A 6, 8
142A-3716-2300 230 VAC K t/c 122°F High limit Automatic Reset 3A Relay Fixed Potted LF E4KW 0122 AAAA A 6, 8
142A-3716-2300 230 VAC K t/c 50°C High limit Automatic Reset 3A Relay Fixed Potted LF E4LW 0050 AAAA A 6, 8
142A-3716-2400 230 VAC K t/c 122°F On/Off Heat 3A Relay Fixed Potted CF E4KH 0122 AAAA A 6, 8
142A-3716-2400 230 VAC K t/c 50°C On/Off Heat 3A Relay Fixed Potted CF E4LH 0050 AAAA A 6, 8
142A-3717-1200 120 VAC K t/c 1382°F High limit Manual Reset 3A Relay Fixed Potted LF C4KU 1382 AAAA A 6, 8
142A-3717-1200 120 VAC K t/c 750°C High limit Manual Reset 3A Relay Fixed Potted LF C4LU 0750 AAAA A 6, 8
142A-3717-1300 120 VAC K t/c 1382°F High limit Automatic Reset 3A Relay Fixed Potted LF C4KW 1382 AAAA A 6, 8
142A-3717-1300 120 VAC K t/c 750°C High limit Automatic Reset 3A Relay Fixed Potted LF C4LW 0750 AAAA A 6, 8
142A-3717-1400 120 VAC K t/c 1382°F On/Off Heat 3A Relay Fixed Potted CF C4KH 1382 AAAA A 6, 8
142A-3717-1400 120 VAC K t/c 750°C On/Off Heat 3A Relay Fixed Potted CF C4LH 0750 AAAA A 6, 8
142A-3717-2200 230 VAC K t/c 1382°F High limit Manual Reset 3A Relay Fixed Potted LF E4KU 1382 AAAA A 6, 8
142A-3717-2200 230 VAC K t/c 750°C High limit Manual Reset 3A Relay Fixed Potted LF E4LU 0750 AAAA A 6, 8
142A-3717-2300 230 VAC K t/c 1382°F High limit Automatic Reset 3A Relay Fixed Potted LF E4KW 1382 AAAA A 6, 8
142A-3717-2300 230 VAC K t/c 750°C High limit Automatic Reset 3A Relay Fixed Potted LF E4LW 0750 AAAA A 6, 8
142A-3717-2400 230 VAC K t/c 1382°F On/Off Heat 3A Relay Fixed Potted CF E4KH 1382 AAAA A 6, 8
142A-3717-2400 230 VAC K t/c 750°C On/Off Heat 3A Relay Fixed Potted CF E4LH 0750 AAAA A 6, 8
142A-3718-1200 120 VAC J t/c 61°F High limit Manual Reset 3A Relay Fixed Potted LF C4HU 0061 AAAA A 6, 8
142A-3718-1200 120 VAC J t/c 16°C High limit Manual Reset 3A Relay Fixed Potted LF C4JU 0016 AAAA A 6, 8
142A-3718-1300 120 VAC J t/c 61°F High limit Automatic Reset 3A Relay Fixed Potted LF C4HW 0061 AAAA A 6, 8
142A-3718-1300 120 VAC J t/c 16°C High limit Automatic Reset 3A Relay Fixed Potted LF C4JW 0016 AAAA A 6, 8
142A-3718-1400 120 VAC J t/c 61°F On/Off Heat 3A Relay Fixed Potted CF C4HH 0061 AAAA A 6, 8
142A-3718-1400 120 VAC J t/c 16°C On/Off Heat 3A Relay Fixed Potted CF C4JH 0016 AAAA A 6, 8
142A-3718-2200 230 VAC J t/c 61°F High limit Manual Reset 3A Relay Fixed Potted LF E4HU 0061 AAAA A 6, 8
142A-3718-2200 230 VAC J t/c 16°C High limit Manual Reset 3A Relay Fixed Potted LF E4JU 0016 AAAA A 6, 8
142A-3718-2300 230 VAC J t/c 61°F High limit Automatic Reset 3A Relay Fixed Potted LF E4HW 0061 AAAA A 6, 8
142A-3718-2300 230 VAC J t/c 16°C High limit Automatic Reset 3A Relay Fixed Potted LF E4JW 0016 AAAA A 6, 8
142A-3718-2400 230 VAC J t/c 61°F On/Off Heat 3A Relay Fixed Potted CF E4HH 0061 AAAA A 6, 8
142A-3718-2400 230 VAC J t/c 16°C On/Off Heat 3A Relay Fixed Potted CF E4JH 0016 AAAA A 6, 8
142A-3719-1200 120 VAC J t/c 230°F High limit Manual Reset 3A Relay Fixed Potted LF C4HU 0230 AAAA A 6, 8
142A-3719-1200 120 VAC J t/c 110°C High limit Manual Reset 3A Relay Fixed Potted LF C4JU 0110 AAAA A 6, 8
142A-3719-1300 120 VAC J t/c 230°F High limit Automatic Reset 3A Relay Fixed Potted LF C4HW 0230 AAAA A 6, 8
142A-3719-1300 120 VAC J t/c 110°C High limit Automatic Reset 3A Relay Fixed Potted LF C4JW 0110 AAAA A 6, 8
142A-3719-1400 120 VAC J t/c 230°F On/Off Heat 3A Relay Fixed Potted CF C4HH 0230 AAAA A 6, 8
142A-3719-1400 120 VAC J t/c 110°C On/Off Heat 3A Relay Fixed Potted CF C4JH 0110 AAAA A 6, 8
142A-3719-2200 230 VAC J t/c 230°F High limit Manual Reset 3A Relay Fixed Potted LF E4HU 0230 AAAA A 6, 8
142A-3719-2200 230 VAC J t/c 110°C High limit Manual Reset 3A Relay Fixed Potted LF E4JU 0110 AAAA A 6, 8
142A-3719-2300 230 VAC J t/c 230°F High limit Automatic Reset 3A Relay Fixed Potted LF E4HW 0230 AAAA A 6, 8
142A-3719-2300 230 VAC J t/c 110°C High limit Automatic Reset 3A Relay Fixed Potted LF E4JW 0110 AAAA A 6, 8
142A-3719-2400 230 VAC J t/c 230°F On/Off Heat 3A Relay Fixed Potted CF E4HH 0230 AAAA A 6, 8
Watlow Controls 1/31/2005 Page 36
