Series 142
Series 142
Line
Voltage Input Temp Range Control Mode Action Output Set Point Mounting Retrofit
See Notes
Below
142A-3631-2400 230 VAC J t/c 510°C On/Off Heat 3A Relay Fixed Potted CF E4JH 0510 AAAA A 6, 8
142A-3632-1200 120 VAC J t/c 975°F High limit Manual Reset 3A Relay Fixed Potted LF C4HU 0975 AAAA A 6, 8
142A-3632-1200 120 VAC J t/c 524°C High limit Manual Reset 3A Relay Fixed Potted LF C4JU 0524 AAAA A 6, 8
142A-3632-1300 120 VAC J t/c 975°F High limit Automatic Reset 3A Relay Fixed Potted LF C4HW 0975 AAAA A 6, 8
142A-3632-1300 120 VAC J t/c 524°C High limit Automatic Reset 3A Relay Fixed Potted LF C4JW 0524 AAAA A 6, 8
142A-3632-1400 120 VAC J t/c 975°F On/Off Heat 3A Relay Fixed Potted CF C4HH 0975 AAAA A 6, 8
142A-3632-1400 120 VAC J t/c 524°C On/Off Heat 3A Relay Fixed Potted CF C4JH 0524 AAAA A 6, 8
142A-3632-2200 230 VAC J t/c 975°F High limit Manual Reset 3A Relay Fixed Potted LF E4HU 0975 AAAA A 6, 8
142A-3632-2200 230 VAC J t/c 524°C High limit Manual Reset 3A Relay Fixed Potted LF E4JU 0524 AAAA A 6, 8
142A-3632-2300 230 VAC J t/c 975°F High limit Automatic Reset 3A Relay Fixed Potted LF E4HW 0975 AAAA A 6, 8
142A-3632-2300 230 VAC J t/c 524°C High limit Automatic Reset 3A Relay Fixed Potted LF E4JW 0524 AAAA A 6, 8
142A-3632-2400 230 VAC J t/c 975°F On/Off Heat 3A Relay Fixed Potted CF E4HH 0975 AAAA A 6, 8
142A-3632-2400 230 VAC J t/c 524°C On/Off Heat 3A Relay Fixed Potted CF E4JH 0524 AAAA A 6, 8
142A-3633-1200 120 VAC J t/c 1000°F High limit Manual Reset 3A Relay Fixed Potted LF C4HU 1000 AAAA A 6, 8
142A-3633-1200 120 VAC J t/c 538°C High limit Manual Reset 3A Relay Fixed Potted LF C4JU 0538 AAAA A 6, 8
142A-3633-1300 120 VAC J t/c 1000°F High limit Automatic Reset 3A Relay Fixed Potted LF C4HW 1000 AAAA A 6, 8
142A-3633-1300 120 VAC J t/c 538°C High limit Automatic Reset 3A Relay Fixed Potted LF C4JW 0538 AAAA A 6, 8
142A-3633-1400 120 VAC J t/c 1000°F On/Off Heat 3A Relay Fixed Potted CF C4HH 1000 AAAA A 6, 8
142A-3633-1400 120 VAC J t/c 538°C On/Off Heat 3A Relay Fixed Potted CF C4JH 0538 AAAA A 6, 8
142A-3633-2200 230 VAC J t/c 1000°F High limit Manual Reset 3A Relay Fixed Potted LF E4HU 1000 AAAA A 6, 8
142A-3633-2200 230 VAC J t/c 538°C High limit Manual Reset 3A Relay Fixed Potted LF E4JU 0538 AAAA A 6, 8
142A-3633-2300 230 VAC J t/c 1000°F High limit Automatic Reset 3A Relay Fixed Potted LF E4HW 1000 AAAA A 6, 8
142A-3633-2300 230 VAC J t/c 538°C High limit Automatic Reset 3A Relay Fixed Potted LF E4JW 0538 AAAA A 6, 8
142A-3633-2400 230 VAC J t/c 1000°F On/Off Heat 3A Relay Fixed Potted CF E4HH 1000 AAAA A 6, 8
142A-3633-2400 230 VAC J t/c 538°C On/Off Heat 3A Relay Fixed Potted CF E4JH 0538 AAAA A 6, 8
142A-3634-1200 120 VAC K t/c 1050°F High limit Manual Reset 3A Relay Fixed Potted LF C4KU 1050 AAAA A 6, 8
142A-3634-1200 120 VAC K t/c 566°C High limit Manual Reset 3A Relay Fixed Potted LF C4LU 0566 AAAA A 6, 8
142A-3634-1300 120 VAC K t/c 1050°F High limit Automatic Reset 3A Relay Fixed Potted LF C4KW 1050 AAAA A 6, 8
142A-3634-1300 120 VAC K t/c 566°C High limit Automatic Reset 3A Relay Fixed Potted LF C4LW 0566 AAAA A 6, 8
142A-3634-1400 120 VAC K t/c 1050°F On/Off Heat 3A Relay Fixed Potted CF C4KH 1050 AAAA A 6, 8
142A-3634-1400 120 VAC K t/c 566°C On/Off Heat 3A Relay Fixed Potted CF C4LH 0566 AAAA A 6, 8
142A-3634-2200 230 VAC K t/c 1050°F High limit Manual Reset 3A Relay Fixed Potted LF E4KU 1050 AAAA A 6, 8
142A-3634-2200 230 VAC K t/c 566°C High limit Manual Reset 3A Relay Fixed Potted LF E4LU 0566 AAAA A 6, 8
142A-3634-2300 230 VAC K t/c 1050°F High limit Automatic Reset 3A Relay Fixed Potted LF E4KW 1050 AAAA A 6, 8
142A-3634-2300 230 VAC K t/c 566°C High limit Automatic Reset 3A Relay Fixed Potted LF E4LW 0566 AAAA A 6, 8
142A-3634-2400 230 VAC K t/c 1050°F On/Off Heat 3A Relay Fixed Potted CF E4KH 1050 AAAA A 6, 8
142A-3634-2400 230 VAC K t/c 566°C On/Off Heat 3A Relay Fixed Potted CF E4LH 0566 AAAA A 6, 8
142A-3635-1200 120 VAC K t/c 1100°F High limit Manual Reset 3A Relay Fixed Potted LF C4KU 1100 AAAA A 6, 8
142A-3635-1200 120 VAC K t/c 537°C High limit Manual Reset 3A Relay Fixed Potted LF C4LU 0537 AAAA A 6, 8
142A-3635-1300 120 VAC K t/c 1100°F High limit Automatic Reset 3A Relay Fixed Potted LF C4KW 1100 AAAA A 6, 8
142A-3635-1300 120 VAC K t/c 537°C High limit Automatic Reset 3A Relay Fixed Potted LF C4LW 0537 AAAA A 6, 8
