Series 142
Series 142
Line
Voltage Input Temp Range Control Mode Action Output Set Point Mounting Retrofit
See Notes
Below
142A-3649-1200 120 VAC K t/c 1800°F High limit Manual Reset 3A Relay Fixed Potted LF C4KU 1800 AAAA A 6, 8
142A-3649-1200 120 VAC K t/c 982°C High limit Manual Reset 3A Relay Fixed Potted LF C4LU 0982 AAAA A 6, 8
142A-3649-1300 120 VAC K t/c 1800°F High limit Automatic Reset 3A Relay Fixed Potted LF C4KW 1800 AAAA A 6, 8
142A-3649-1300 120 VAC K t/c 982°C High limit Automatic Reset 3A Relay Fixed Potted LF C4LW 0982 AAAA A 6, 8
142A-3649-1400 120 VAC K t/c 1800°F On/Off Heat 3A Relay Fixed Potted CF C4KH 1800 AAAA A 6, 8
142A-3649-1400 120 VAC K t/c 982°C On/Off Heat 3A Relay Fixed Potted CF C4LH 0982 AAAA A 6, 8
142A-3649-2200 230 VAC K t/c 1800°F High limit Manual Reset 3A Relay Fixed Potted LF E4KU 1800 AAAA A 6, 8
142A-3649-2200 230 VAC K t/c 982°C High limit Manual Reset 3A Relay Fixed Potted LF E4LU 0982 AAAA A 6, 8
142A-3649-2300 230 VAC K t/c 1800°F High limit Automatic Reset 3A Relay Fixed Potted LF E4KW 1800 AAAA A 6, 8
142A-3649-2300 230 VAC K t/c 982°C High limit Automatic Reset 3A Relay Fixed Potted LF E4LW 0982 AAAA A 6, 8
142A-3649-2400 230 VAC K t/c 1800°F On/Off Heat 3A Relay Fixed Potted CF E4KH 1800 AAAA A 6, 8
142A-3649-2400 230 VAC K t/c 982°C On/Off Heat 3A Relay Fixed Potted CF E4LH 0982 AAAA A 6, 8
142A-3650-1200 120 VAC K t/c 1850°F High limit Manual Reset 3A Relay Fixed Potted LF C4KU 1850 AAAA A 6, 8
142A-3650-1200 120 VAC K t/c 1010°C High limit Manual Reset 3A Relay Fixed Potted LF C4LU 1010 AAAA A 6, 8
142A-3650-1300 120 VAC K t/c 1850°F High limit Automatic Reset 3A Relay Fixed Potted LF C4KW 1850 AAAA A 6, 8
142A-3650-1300 120 VAC K t/c 1010°C High limit Automatic Reset 3A Relay Fixed Potted LF C4LW 1010 AAAA A 6, 8
142A-3650-1400 120 VAC K t/c 1850°F On/Off Heat 3A Relay Fixed Potted CF C4KH 1850 AAAA A 6, 8
142A-3650-1400 120 VAC K t/c 1010°C On/Off Heat 3A Relay Fixed Potted CF C4LH 1010 AAAA A 6, 8
142A-3650-2200 230 VAC K t/c 1850°F High limit Manual Reset 3A Relay Fixed Potted LF E4KU 1850 AAAA A 6, 8
142A-3650-2200 230 VAC K t/c 1010°C High limit Manual Reset 3A Relay Fixed Potted LF E4LU 1010 AAAA A 6, 8
142A-3650-2300 230 VAC K t/c 1850°F High limit Automatic Reset 3A Relay Fixed Potted LF E4KW 1850 AAAA A 6, 8
142A-3650-2300 230 VAC K t/c 1010°C High limit Automatic Reset 3A Relay Fixed Potted LF E4LW 1010 AAAA A 6, 8
142A-3650-2400 230 VAC K t/c 1850°F On/Off Heat 3A Relay Fixed Potted CF E4KH 1850 AAAA A 6, 8
142A-3650-2400 230 VAC K t/c 1010°C On/Off Heat 3A Relay Fixed Potted CF E4LH 1010 AAAA A 6, 8
142A-3651-1200 120 VAC K t/c 1900°F High limit Manual Reset 3A Relay Fixed Potted LF C4KU 1900 AAAA A 6, 8
142A-3651-1200 120 VAC K t/c 1038°C High limit Manual Reset 3A Relay Fixed Potted LF C4LU 1038 AAAA A 6, 8
142A-3651-1300 120 VAC K t/c 1900°F High limit Automatic Reset 3A Relay Fixed Potted LF C4KW 1900 AAAA A 6, 8
142A-3651-1300 120 VAC K t/c 1038°C High limit Automatic Reset 3A Relay Fixed Potted LF C4LW 1038 AAAA A 6, 8
142A-3651-1400 120 VAC K t/c 1900°F On/Off Heat 3A Relay Fixed Potted CF C4KH 1900 AAAA A 6, 8
142A-3651-1400 120 VAC K t/c 1038°C On/Off Heat 3A Relay Fixed Potted CF C4LH 1038 AAAA A 6, 8
142A-3651-2200 230 VAC K t/c 1900°F High limit Manual Reset 3A Relay Fixed Potted LF E4KU 1900 AAAA A 6, 8
142A-3651-2200 230 VAC K t/c 1038°C High limit Manual Reset 3A Relay Fixed Potted LF E4LU 1038 AAAA A 6, 8
142A-3651-2300 230 VAC K t/c 1900°F High limit Automatic Reset 3A Relay Fixed Potted LF E4KW 1900 AAAA A 6, 8
142A-3651-2300 230 VAC K t/c 1038°C High limit Automatic Reset 3A Relay Fixed Potted LF E4LW 1038 AAAA A 6, 8
142A-3651-2400 230 VAC K t/c 1900°F On/Off Heat 3A Relay Fixed Potted CF E4KH 1900 AAAA A 6, 8
142A-3651-2400 230 VAC K t/c 1038°C On/Off Heat 3A Relay Fixed Potted CF E4LH 1038 AAAA A 6, 8
142A-3652-1200 120 VAC K t/c 1950°F High limit Manual Reset 3A Relay Fixed Potted LF C4KU 1950 AAAA A 6, 8
142A-3652-1200 120 VAC K t/c 1066°C High limit Manual Reset 3A Relay Fixed Potted LF C4LU 1066 AAAA A 6, 8
142A-3652-1300 120 VAC K t/c 1950°F High limit Automatic Reset 3A Relay Fixed Potted LF C4KW 1950 AAAA A 6, 8
142A-3652-1300 120 VAC K t/c 1066°C High limit Automatic Reset 3A Relay Fixed Potted LF C4LW 1066 AAAA A 6, 8
142A-3652-1400 120 VAC K t/c 1950°F On/Off Heat 3A Relay Fixed Potted CF C4KH 1950 AAAA A 6, 8
Watlow Controls 1/31/2005 Page 18
