Series 142
Series 142
Line
Voltage Input Temp Range Control Mode Action Output Set Point Mounting Retrofit
See Notes
Below
142A-3642-1300 120 VAC K t/c 1450°F High limit Automatic Reset 3A Relay Fixed Potted LF C4KW 1450 AAAA A 6, 8
142A-3642-1300 120 VAC K t/c 788°C High limit Automatic Reset 3A Relay Fixed Potted LF C4LW 0788 AAAA A 6, 8
142A-3642-1400 120 VAC K t/c 1450°F On/Off Heat 3A Relay Fixed Potted CF C4KH 1450 AAAA A 6, 8
142A-3642-1400 120 VAC K t/c 788°C On/Off Heat 3A Relay Fixed Potted CF C4LH 0788 AAAA A 6, 8
142A-3642-2200 230 VAC K t/c 1450°F High limit Manual Reset 3A Relay Fixed Potted LF E4KU 1450 AAAA A 6, 8
142A-3642-2200 230 VAC K t/c 788°C High limit Manual Reset 3A Relay Fixed Potted LF E4LU 0788 AAAA A 6, 8
142A-3642-2300 230 VAC K t/c 1450°F High limit Automatic Reset 3A Relay Fixed Potted LF E4KW 1450 AAAA A 6, 8
142A-3642-2300 230 VAC K t/c 788°C High limit Automatic Reset 3A Relay Fixed Potted LF E4LW 0788 AAAA A 6, 8
142A-3642-2400 230 VAC K t/c 1450°F On/Off Heat 3A Relay Fixed Potted CF E4KH 1450 AAAA A 6, 8
142A-3642-2400 230 VAC K t/c 788°C On/Off Heat 3A Relay Fixed Potted CF E4LH 0788 AAAA A 6, 8
142A-3643-1200 120 VAC K t/c 1500°F High limit Manual Reset 3A Relay Fixed Potted LF C4KU 1500 AAAA A 6, 8
142A-3643-1200 120 VAC K t/c 816°C High limit Manual Reset 3A Relay Fixed Potted LF C4LU 0816 AAAA A 6, 8
142A-3643-1300 120 VAC K t/c 1500°F High limit Automatic Reset 3A Relay Fixed Potted LF C4KW 1500 AAAA A 6, 8
142A-3643-1300 120 VAC K t/c 816°C High limit Automatic Reset 3A Relay Fixed Potted LF C4LW 0816 AAAA A 6, 8
142A-3643-1400 120 VAC K t/c 1500°F On/Off Heat 3A Relay Fixed Potted CF C4KH 1500 AAAA A 6, 8
142A-3643-1400 120 VAC K t/c 816°C On/Off Heat 3A Relay Fixed Potted CF C4LH 0816 AAAA A 6, 8
142A-3643-2200 230 VAC K t/c 1500°F High limit Manual Reset 3A Relay Fixed Potted LF E4KU 1500 AAAA A 6, 8
142A-3643-2200 230 VAC K t/c 816°C High limit Manual Reset 3A Relay Fixed Potted LF E4LU 0816 AAAA A 6, 8
142A-3643-2300 230 VAC K t/c 1500°F High limit Automatic Reset 3A Relay Fixed Potted LF E4KW 1500 AAAA A 6, 8
142A-3643-2300 230 VAC K t/c 816°C High limit Automatic Reset 3A Relay Fixed Potted LF E4LW 0816 AAAA A 6, 8
142A-3643-2400 230 VAC K t/c 1500°F On/Off Heat 3A Relay Fixed Potted CF E4KH 1500 AAAA A 6, 8
142A-3643-2400 230 VAC K t/c 816°C On/Off Heat 3A Relay Fixed Potted CF E4LH 0816 AAAA A 6, 8
142A-3644-1200 120 VAC K t/c 1550°F High limit Manual Reset 3A Relay Fixed Potted LF C4KU 1550 AAAA A 6, 8
142A-3644-1200 120 VAC K t/c 843°C High limit Manual Reset 3A Relay Fixed Potted LF C4LU 0843 AAAA A 6, 8
142A-3644-1300 120 VAC K t/c 1550°F High limit Automatic Reset 3A Relay Fixed Potted LF C4KW 1550 AAAA A 6, 8
142A-3644-1300 120 VAC K t/c 843°C High limit Automatic Reset 3A Relay Fixed Potted LF C4LW 0843 AAAA A 6, 8
142A-3644-1400 120 VAC K t/c 1550°F On/Off Heat 3A Relay Fixed Potted CF C4KH 1550 AAAA A 6, 8
142A-3644-1400 120 VAC K t/c 843°C On/Off Heat 3A Relay Fixed Potted CF C4LH 0843 AAAA A 6, 8
142A-3644-2200 230 VAC K t/c 1550°F High limit Manual Reset 3A Relay Fixed Potted LF E4KU 1550 AAAA A 6, 8
142A-3644-2200 230 VAC K t/c 843°C High limit Manual Reset 3A Relay Fixed Potted LF E4LU 0843 AAAA A 6, 8
142A-3644-2300 230 VAC K t/c 1550°F High limit Automatic Reset 3A Relay Fixed Potted LF E4KW 1550 AAAA A 6, 8
142A-3644-2300 230 VAC K t/c 843°C High limit Automatic Reset 3A Relay Fixed Potted LF E4LW 0843 AAAA A 6, 8
142A-3644-2400 230 VAC K t/c 1550°F On/Off Heat 3A Relay Fixed Potted CF E4KH 1550 AAAA A 6, 8
142A-3644-2400 230 VAC K t/c 843°C On/Off Heat 3A Relay Fixed Potted CF E4LH 0843 AAAA A 6, 8
142A-3645-1200 120 VAC K t/c 1600°F High limit Manual Reset 3A Relay Fixed Potted LF C4KU 1600 AAAA A 6, 8
142A-3645-1200 120 VAC K t/c 871°C High limit Manual Reset 3A Relay Fixed Potted LF C4LU 0871 AAAA A 6, 8
142A-3645-1300 120 VAC K t/c 1600°F High limit Automatic Reset 3A Relay Fixed Potted LF C4KW 1600 AAAA A 6, 8
142A-3645-1300 120 VAC K t/c 871°C High limit Automatic Reset 3A Relay Fixed Potted LF C4LW 0871 AAAA A 6, 8
142A-3645-1400 120 VAC K t/c 1600°F On/Off Heat 3A Relay Fixed Potted CF C4KH 1600 AAAA A 6, 8
142A-3645-1400 120 VAC K t/c 871°C On/Off Heat 3A Relay Fixed Potted CF C4LH 0871 AAAA A 6, 8
142A-3645-2200 230 VAC K t/c 1600°F High limit Manual Reset 3A Relay Fixed Potted LF E4KU 1600 AAAA A 6, 8
Watlow Controls 1/31/2005 Page 16
