Series 142
Series 142
Line
Voltage Input Temp Range Control Mode Action Output Set Point Mounting Retrofit
See Notes
Below
142A-3611-1400 120 VAC J t/c 116°C On/Off Heat 3A Relay Fixed Potted CF C4JH 0116 AAAA A 6, 8
142A-3611-2200 230 VAC J t/c 240°F High limit Manual Reset 3A Relay Fixed Potted LF E4HU 0240 AAAA A 6, 8
142A-3611-2200 230 VAC J t/c 116°C High limit Manual Reset 3A Relay Fixed Potted LF E4JU 0116 AAAA A 6, 8
142A-3611-2300 230 VAC J t/c 240°F High limit Automatic Reset 3A Relay Fixed Potted LF E4HW 0240 AAAA A 6, 8
142A-3611-2300 230 VAC J t/c 116°C High limit Automatic Reset 3A Relay Fixed Potted LF E4JW 0116 AAAA A 6, 8
142A-3611-2400 230 VAC J t/c 240°F On/Off Heat 3A Relay Fixed Potted CF E4HH 0240 AAAA A 6, 8
142A-3611-2400 230 VAC J t/c 116°C On/Off Heat 3A Relay Fixed Potted CF E4JH 0116 AAAA A 6, 8
142A-3612-1200 120 VAC J t/c 475°F High limit Manual Reset 3A Relay Fixed Potted LF C4HU 0475 AAAA A 6, 8
142A-3612-1200 120 VAC J t/c 246°C High limit Manual Reset 3A Relay Fixed Potted LF C4JU 0246 AAAA A 6, 8
142A-3612-1300 120 VAC J t/c 475°F High limit Automatic Reset 3A Relay Fixed Potted LF C4HW 0475 AAAA A 6, 8
142A-3612-1300 120 VAC J t/c 246°C High limit Automatic Reset 3A Relay Fixed Potted LF C4JW 0246 AAAA A 6, 8
142A-3612-1400 120 VAC J t/c 475°F On/Off Heat 3A Relay Fixed Potted CF C4HH 0475 AAAA A 6, 8
142A-3612-1400 120 VAC J t/c 246°C On/Off Heat 3A Relay Fixed Potted CF C4JH 0246 AAAA A 6, 8
142A-3612-2200 230 VAC J t/c 475°F High limit Manual Reset 3A Relay Fixed Potted LF E4HU 0475 AAAA A 6, 8
142A-3612-2200 230 VAC J t/c 246°C High limit Manual Reset 3A Relay Fixed Potted LF E4JU 0246 AAAA A 6, 8
142A-3612-2300 230 VAC J t/c 475°F High limit Automatic Reset 3A Relay Fixed Potted LF E4HW 0475 AAAA A 6, 8
142A-3612-2300 230 VAC J t/c 246°C High limit Automatic Reset 3A Relay Fixed Potted LF E4JW 0246 AAAA A 6, 8
142A-3612-2400 230 VAC J t/c 475°F On/Off Heat 3A Relay Fixed Potted CF E4HH 0475 AAAA A 6, 8
142A-3612-2400 230 VAC J t/c 246°C On/Off Heat 3A Relay Fixed Potted CF E4JH 0246 AAAA A 6, 8
142A-3613-1200 120 VAC J t/c 500°F High limit Manual Reset 3A Relay Fixed Potted LF C4HU 0500 AAAA A 6, 8
142A-3613-1200 120 VAC J t/c 260°C High limit Manual Reset 3A Relay Fixed Potted LF C4JU 0260 AAAA A 6, 8
142A-3613-1300 120 VAC J t/c 500°F High limit Automatic Reset 3A Relay Fixed Potted LF C4HW 0500 AAAA A 6, 8
142A-3613-1300 120 VAC J t/c 260°C High limit Automatic Reset 3A Relay Fixed Potted LF C4JW 0260 AAAA A 6, 8
142A-3613-1400 120 VAC J t/c 500°F On/Off Heat 3A Relay Fixed Potted CF C4HH 0500 AAAA A 6, 8
142A-3613-1400 120 VAC J t/c 260°C On/Off Heat 3A Relay Fixed Potted CF C4JH 0260 AAAA A 6, 8
142A-3613-2200 230 VAC J t/c 500°F High limit Manual Reset 3A Relay Fixed Potted LF E4HU 0500 AAAA A 6, 8
142A-3613-2200 230 VAC J t/c 260°C High limit Manual Reset 3A Relay Fixed Potted LF E4JU 0260 AAAA A 6, 8
142A-3613-2300 230 VAC J t/c 500°F High limit Automatic Reset 3A Relay Fixed Potted LF E4HW 0500 AAAA A 6, 8
142A-3613-2300 230 VAC J t/c 260°C High limit Automatic Reset 3A Relay Fixed Potted LF E4JW 0260 AAAA A 6, 8
142A-3613-2400 230 VAC J t/c 500°F On/Off Heat 3A Relay Fixed Potted CF E4HH 0500 AAAA A 6, 8
142A-3613-2400 230 VAC J t/c 260°C On/Off Heat 3A Relay Fixed Potted CF E4JH 0260 AAAA A 6, 8
142A-3614-1200 120 VAC J t/c 525°F High limit Manual Reset 3A Relay Fixed Potted LF C4HU 0525 AAAA A 6, 8
142A-3614-1200 120 VAC J t/c 274°C High limit Manual Reset 3A Relay Fixed Potted LF C4JU 0274 AAAA A 6, 8
142A-3614-1300 120 VAC J t/c 525°F High limit Automatic Reset 3A Relay Fixed Potted LF C4HW 0525 AAAA A 6, 8
142A-3614-1300 120 VAC J t/c 274°C High limit Automatic Reset 3A Relay Fixed Potted LF C4JW 0274 AAAA A 6, 8
142A-3614-1400 120 VAC J t/c 525°F On/Off Heat 3A Relay Fixed Potted CF C4HH 0525 AAAA A 6, 8
142A-3614-1400 120 VAC J t/c 274°C On/Off Heat 3A Relay Fixed Potted CF C4JH 0274 AAAA A 6, 8
142A-3614-2200 230 VAC J t/c 525°F High limit Manual Reset 3A Relay Fixed Potted LF E4HU 0525 AAAA A 6, 8
142A-3614-2200 230 VAC J t/c 274°C High limit Manual Reset 3A Relay Fixed Potted LF E4JU 0274 AAAA A 6, 8
142A-3614-2300 230 VAC J t/c 525°F High limit Automatic Reset 3A Relay Fixed Potted LF E4HW 0525 AAAA A 6, 8
142A-3614-2300 230 VAC J t/c 274°C High limit Automatic Reset 3A Relay Fixed Potted LF E4JW 0274 AAAA A 6, 8
Watlow Controls 1/31/2005 Page 7
