Series 142
Series 142
Line
Voltage
Input
Temp Range
Control Mode
Action
Output
Set Point
Mounting
Retrofit
See Notes
Below
142A-3699-2400
230 VAC
J t/c
425°F
On/Off
Heat
3A Relay
Fixed
Potted
CF E4HH 0425 AAAA A
6, 8
142A-3699-2400
230 VAC
J t/c
218°C
On/Off
Heat
3A Relay
Fixed
Potted
CF E4JH 0218 AAAA A
6, 8
142A-3700-1200
120 VAC
K t/c
200°F
High limit
Manual Reset
3A Relay
Fixed
Potted
LF C4KU 0200 AAAA A
6, 8
142A-3700-1200
120 VAC
K t/c
93°C
High limit
Manual Reset
3A Relay
Fixed
Potted
LF C4LU 0093 AAAA A
6, 8
142A-3700-1300
120 VAC
K t/c
200°F
High limit
Automatic Reset
3A Relay
Fixed
Potted
LF C4KW 0200 AAAA A
6, 8
142A-3700-1300
120 VAC
K t/c
93°C
High limit
Automatic Reset
3A Relay
Fixed
Potted
LF C4LW 0093 AAAA A
6, 8
142A-3700-1400
120 VAC
K t/c
200°F
On/Off
Heat
3A Relay
Fixed
Potted
CF C4KH 0200 AAAA A
6, 8
142A-3700-1400
120 VAC
K t/c
93°C
On/Off
Heat
3A Relay
Fixed
Potted
CF C4LH 0093 AAAA A
6, 8
142A-3700-2200
230 VAC
K t/c
200°F
High limit
Manual Reset
3A Relay
Fixed
Potted
LF E4KU 0200 AAAA A
6, 8
142A-3700-2200
230 VAC
K t/c
93°C
High limit
Manual Reset
3A Relay
Fixed
Potted
LF E4LU 0093 AAAA A
6, 8
142A-3700-2300
230 VAC
K t/c
200°F
High limit
Automatic Reset
3A Relay
Fixed
Potted
LF E4KW 0200 AAAA A
6, 8
142A-3700-2300
230 VAC
K t/c
93°C
High limit
Automatic Reset
3A Relay
Fixed
Potted
LF E4LW 0093 AAAA A
6, 8
142A-3700-2400
230 VAC
K t/c
200°F
On/Off
Heat
3A Relay
Fixed
Potted
CF E4KH 0200 AAAA A
6, 8
142A-3700-2400
230 VAC
K t/c
93°C
On/Off
Heat
3A Relay
Fixed
Potted
CF E4LH 0093 AAAA A
6, 8
142A-3701-1200
120 VAC
K t/c
150°F
High limit
Manual Reset
3A Relay
Fixed
Potted
LF C4KU 0150 AAAA A
6, 8
142A-3701-1200
120 VAC
K t/c
66°C
High limit
Manual Reset
3A Relay
Fixed
Potted
LF C4LU 0066 AAAA A
6, 8
142A-3701-1300
120 VAC
K t/c
150°F
High limit
Automatic Reset
3A Relay
Fixed
Potted
LF C4KW 0150 AAAA A
6, 8
142A-3701-1300
120 VAC
K t/c
66°C
High limit
Automatic Reset
3A Relay
Fixed
Potted
LF C4LW 0066 AAAA A
6, 8
142A-3701-1400
120 VAC
K t/c
150°F
On/Off
Heat
3A Relay
Fixed
Potted
CF C4KH 0150 AAAA A
6, 8
142A-3701-1400
120 VAC
K t/c
66°C
On/Off
Heat
3A Relay
Fixed
Potted
CF C4LH 0066 AAAA A
6, 8
142A-3701-2200
230 VAC
K t/c
150°F
High limit
Manual Reset
3A Relay
Fixed
Potted
LF E4KU 0150 AAAA A
6, 8
142A-3701-2200
230 VAC
K t/c
66°C
High limit
Manual Reset
3A Relay
Fixed
Potted
LF E4LU 0066 AAAA A
6, 8
142A-3701-2300
230 VAC
K t/c
150°F
High limit
Automatic Reset
3A Relay
Fixed
Potted
LF E4KW 0150 AAAA A
6, 8
142A-3701-2300
230 VAC
K t/c
66°C
High limit
Automatic Reset
3A Relay
Fixed
Potted
LF E4LW 0066 AAAA A
6, 8
142A-3701-2400
230 VAC
K t/c
150°F
On/Off
Heat
3A Relay
Fixed
Potted
CF E4KH 0150 AAAA A
6, 8
142A-3701-2400
230 VAC
K t/c
66°C
On/Off
Heat
3A Relay
Fixed
Potted
CF E4LH 0066 AAAA A
6, 8
142A-3703-1200
120 VAC
K t/c
140°F
High limit
Manual Reset
3A Relay
Fixed
Potted
LF C4KU 0140 AAAA A
6, 8
142A-3703-1200
120 VAC
K t/c
60°C
High limit
Manual Reset
3A Relay
Fixed
Potted
LF C4LU 0060 AAAA A
6, 8
142A-3703-1300
120 VAC
K t/c
140°F
High limit
Automatic Reset
3A Relay
Fixed
Potted
LF C4KW 0140 AAAA A
6, 8
142A-3703-1300
120 VAC
K t/c
60°C
High limit
Automatic Reset
3A Relay
Fixed
Potted
LF C4LW 0060 AAAA A
6, 8
142A-3703-1400
120 VAC
K t/c
140°F
On/Off
Heat
3A Relay
Fixed
Potted
CF C4KH 0140 AAAA A
6, 8
142A-3703-1400
120 VAC
K t/c
60°C
On/Off
Heat
3A Relay
Fixed
Potted
CF C4LH 0060 AAAA A
6, 8
142A-3703-2200
230 VAC
K t/c
140°F
High limit
Manual Reset
3A Relay
Fixed
Potted
LF E4KU 0140 AAAA A
6, 8
142A-3703-2200
230 VAC
K t/c
60°C
High limit
Manual Reset
3A Relay
Fixed
Potted
LF E4LU 0060 AAAA A
6, 8
142A-3703-2300
230 VAC
K t/c
140°F
High limit
Automatic Reset
3A Relay
Fixed
Potted
LF E4KW 0140 AAAA A
6, 8
142A-3703-2300
230 VAC
K t/c
60°C
High limit
Automatic Reset
3A Relay
Fixed
Potted
LF E4LW 0060 AAAA A
6, 8
142A-3703-2400
230 VAC
K t/c
140°F
On/Off
Heat
3A Relay
Fixed
Potted
CF E4KH 0140 AAAA A
6, 8
142A-3703-2400
230 VAC
K t/c
60°C
On/Off
Heat
3A Relay
Fixed
Potted
CF E4LH 0060 AAAA A
6, 8
142A-3704-1200
120 VAC
J t/c
465°F
High limit
Manual Reset
3A Relay
Fixed
Potted
LF C4HU 0465 AAAA A
6, 8
142A-3704-1200
120 VAC
J t/c
241°C
High limit
Manual Reset
3A Relay
Fixed
Potted
LF C4JU 0241 AAAA A
6, 8
142A-3704-1300
120 VAC
J t/c
465°F
High limit
Automatic Reset
3A Relay
Fixed
Potted
LF C4HW 0465 AAAA A
6, 8
