Series 142
Series 142
Line
Voltage Input Temp Range Control Mode Action Output Set Point Mounting Retrofit
See Notes
Below
142A-3713-1200 120 VAC T t/c 200°C High limit Manual Reset 3A Relay Fixed Potted LF C4NU 0200 AAAA A 6, 8
142A-3713-1300 120 VAC T t/c 392°F High limit Automatic Reset 3A Relay Fixed Potted LF C4MW 0392 AAAA A 6, 8
142A-3713-1300 120 VAC T t/c 200°C High limit Automatic Reset 3A Relay Fixed Potted LF C4NW 0200 AAAA A 6, 8
142A-3713-1400 120 VAC T t/c 392°F On/Off Heat 3A Relay Fixed Potted CF C4MH 0392 AAAA A 6, 8
142A-3713-1400 120 VAC T t/c 200°C On/Off Heat 3A Relay Fixed Potted CF C4NH 0200 AAAA A 6, 8
142A-3713-2200 230 VAC T t/c 392°F High limit Manual Reset 3A Relay Fixed Potted LF E4MU 0392 AAAA A 6, 8
142A-3713-2200 230 VAC T t/c 200°C High limit Manual Reset 3A Relay Fixed Potted LF E4NU 0200 AAAA A 6, 8
142A-3713-2300 230 VAC T t/c 392°F High limit Automatic Reset 3A Relay Fixed Potted LF E4MW 0392 AAAA A 6, 8
142A-3713-2300 230 VAC T t/c 200°C High limit Automatic Reset 3A Relay Fixed Potted LF E4NW 0200 AAAA A 6, 8
142A-3713-2400 230 VAC T t/c 392°F On/Off Heat 3A Relay Fixed Potted CF E4MH 0392 AAAA A 6, 8
142A-3713-2400 230 VAC T t/c 200°C On/Off Heat 3A Relay Fixed Potted CF E4NH 0200 AAAA A 6, 8
142A-3714-1200 120 VAC T t/c 175°F High limit Manual Reset 3A Relay Fixed Potted LF C4MU 0175 AAAA A 6, 8
142A-3714-1200 120 VAC T t/c 79°C High limit Manual Reset 3A Relay Fixed Potted LF C4NU 0079 AAAA A 6, 8
142A-3714-1300 120 VAC T t/c 175°F High limit Automatic Reset 3A Relay Fixed Potted LF C4MW 0175 AAAA A 6, 8
142A-3714-1300 120 VAC T t/c 79°C High limit Automatic Reset 3A Relay Fixed Potted LF C4NW 0079 AAAA A 6, 8
142A-3714-1400 120 VAC T t/c 175°F On/Off Heat 3A Relay Fixed Potted CF C4MH 0175 AAAA A 6, 8
142A-3714-1400 120 VAC T t/c 79°C On/Off Heat 3A Relay Fixed Potted CF C4NH 0079 AAAA A 6, 8
142A-3714-2200 230 VAC T t/c 175°F High limit Manual Reset 3A Relay Fixed Potted LF E4MU 0175 AAAA A 6, 8
142A-3714-2200 230 VAC T t/c 79°C High limit Manual Reset 3A Relay Fixed Potted LF E4NU 0079 AAAA A 6, 8
142A-3714-2300 230 VAC T t/c 175°F High limit Automatic Reset 3A Relay Fixed Potted LF E4MW 0175 AAAA A 6, 8
142A-3714-2300 230 VAC T t/c 79°C High limit Automatic Reset 3A Relay Fixed Potted LF E4NW 0079 AAAA A 6, 8
142A-3714-2400 230 VAC T t/c 175°F On/Off Heat 3A Relay Fixed Potted CF E4MH 0175 AAAA A 6, 8
142A-3714-2400 230 VAC T t/c 79°C On/Off Heat 3A Relay Fixed Potted CF E4NH 0079 AAAA A 6, 8
142A-3715-1200 120 VAC J t/c 265°F High limit Manual Reset 3A Relay Fixed Potted LF C4HU 00265 AAAA A 6, 8
142A-3715-1200 120 VAC J t/c 129°C High limit Manual Reset 3A Relay Fixed Potted LF C4JU 0129 AAAA A 6, 8
142A-3715-1300 120 VAC J t/c 265°F High limit Automatic Reset 3A Relay Fixed Potted LF C4HW 00265 AAAA A 6, 8
142A-3715-1300 120 VAC J t/c 129°C High limit Automatic Reset 3A Relay Fixed Potted LF C4JW 0129 AAAA A 6, 8
142A-3715-1400 120 VAC J t/c 265°F On/Off Heat 3A Relay Fixed Potted CF C4HH 00265 AAAA A 6, 8
142A-3715-1400 120 VAC J t/c 129°C On/Off Heat 3A Relay Fixed Potted CF C4JH 0129 AAAA A 6, 8
142A-3715-2200 230 VAC J t/c 265°F High limit Manual Reset 3A Relay Fixed Potted LF E4HU 00265 AAAA A 6, 8
142A-3715-2200 230 VAC J t/c 129°C High limit Manual Reset 3A Relay Fixed Potted LF E4JU 0129 AAAA A 6, 8
142A-3715-2300 230 VAC J t/c 265°F High limit Automatic Reset 3A Relay Fixed Potted LF E4HW 00265 AAAA A 6, 8
142A-3715-2300 230 VAC J t/c 129°C High limit Automatic Reset 3A Relay Fixed Potted LF E4JW 0129 AAAA A 6, 8
142A-3715-2400 230 VAC J t/c 265°F On/Off Heat 3A Relay Fixed Potted CF E4HH 00265 AAAA A 6, 8
142A-3715-2400 230 VAC J t/c 129°C On/Off Heat 3A Relay Fixed Potted CF E4JH 0129 AAAA A 6, 8
142A-3716-1200 120 VAC K t/c 122°F High limit Manual Reset 3A Relay Fixed Potted LF C4KU 0122 AAAA A 6, 8
142A-3716-1200 120 VAC K t/c 50°C High limit Manual Reset 3A Relay Fixed Potted LF C4LU 0050 AAAA A 6, 8
142A-3716-1300 120 VAC K t/c 122°F High limit Automatic Reset 3A Relay Fixed Potted LF C4KW 0122 AAAA A 6, 8
142A-3716-1300 120 VAC K t/c 50°C High limit Automatic Reset 3A Relay Fixed Potted LF C4LW 0050 AAAA A 6, 8
142A-3716-1400 120 VAC K t/c 122°F On/Off Heat 3A Relay Fixed Potted CF C4KH 0122 AAAA A 6, 8
142A-3716-1400 120 VAC K t/c 50°C On/Off Heat 3A Relay Fixed Potted CF C4LH 0050 AAAA A 6, 8
Watlow Controls 1/31/2005 Page 35
