Series 142
Series 142
Line
Voltage Input Temp Range Control Mode Action Output Set Point Mounting Retrofit
See Notes
Below
142A-3692-1200 120 VAC K t/c 2000°F High limit Manual Reset 3A Relay Fixed Potted LF C4KU 2000 AAAA A 6, 8
142A-3692-1200 120 VAC K t/c 1093°C High limit Manual Reset 3A Relay Fixed Potted LF C4LU 1093 AAAA A 6, 8
142A-3692-1300 120 VAC K t/c 2000°F High limit Automatic Reset 3A Relay Fixed Potted LF C4KW 2000 AAAA A 6, 8
142A-3692-1300 120 VAC K t/c 1093°C High limit Automatic Reset 3A Relay Fixed Potted LF C4LW 1093 AAAA A 6, 8
142A-3692-1400 120 VAC K t/c 2000°F On/Off Heat 3A Relay Fixed Potted CF C4KH 2000 AAAA A 6, 8
142A-3692-1400 120 VAC K t/c 1093°C On/Off Heat 3A Relay Fixed Potted CF C4LH 1093 AAAA A 6, 8
142A-3692-2200 230 VAC K t/c 2000°F High limit Manual Reset 3A Relay Fixed Potted LF E4KU 2000 AAAA A 6, 8
142A-3692-2200 230 VAC K t/c 1093°C High limit Manual Reset 3A Relay Fixed Potted LF E4LU 1093 AAAA A 6, 8
142A-3692-2300 230 VAC K t/c 2000°F High limit Automatic Reset 3A Relay Fixed Potted LF E4KW 2000 AAAA A 6, 8
142A-3692-2300 230 VAC K t/c 1093°C High limit Automatic Reset 3A Relay Fixed Potted LF E4LW 1093 AAAA A 6, 8
142A-3692-2400 230 VAC K t/c 2000°F On/Off Heat 3A Relay Fixed Potted CF E4KH 2000 AAAA A 6, 8
142A-3692-2400 230 VAC K t/c 1093°C On/Off Heat 3A Relay Fixed Potted CF E4LH 1093 AAAA A 6, 8
142A-3693-1200 120 VAC J t/c 650°F High limit Manual Reset 3A Relay Fixed Potted LF C4HU 0650 AAAA A 6, 8
142A-3693-1200 120 VAC J t/c 343°C High limit Manual Reset 3A Relay Fixed Potted LF C4JU 0343 AAAA A 6, 8
142A-3693-1300 120 VAC J t/c 650°F High limit Automatic Reset 3A Relay Fixed Potted LF C4HW 0650 AAAA A 6, 8
142A-3693-1300 120 VAC J t/c 343°C High limit Automatic Reset 3A Relay Fixed Potted LF C4JW 0343 AAAA A 6, 8
142A-3693-1400 120 VAC J t/c 650°F On/Off Heat 3A Relay Fixed Potted CF C4HH 0650 AAAA A 6, 8
142A-3693-1400 120 VAC J t/c 343°C On/Off Heat 3A Relay Fixed Potted CF C4JH 0343 AAAA A 6, 8
142A-3693-2200 230 VAC J t/c 650°F High limit Manual Reset 3A Relay Fixed Potted LF E4HU 0650 AAAA A 6, 8
142A-3693-2200 230 VAC J t/c 343°C High limit Manual Reset 3A Relay Fixed Potted LF E4JU 0343 AAAA A 6, 8
142A-3693-2300 230 VAC J t/c 650°F High limit Automatic Reset 3A Relay Fixed Potted LF E4HW 0650 AAAA A 6, 8
142A-3693-2300 230 VAC J t/c 343°C High limit Automatic Reset 3A Relay Fixed Potted LF E4JW 0343 AAAA A 6, 8
142A-3693-2400 230 VAC J t/c 650°F On/Off Heat 3A Relay Fixed Potted CF E4HH 0650 AAAA A 6, 8
142A-3693-2400 230 VAC J t/c 343°C On/Off Heat 3A Relay Fixed Potted CF E4JH 0343 AAAA A 6, 8
142A-3694-1200 120 VAC T t/c 275°F High limit Manual Reset 3A Relay Fixed Potted LF C4MU 0275 AAAA A 6, 8
142A-3694-1200 120 VAC T t/c 135°C High limit Manual Reset 3A Relay Fixed Potted LF C4NU 0135 AAAA A 6, 8
142A-3694-1300 120 VAC T t/c 275°F High limit Automatic Reset 3A Relay Fixed Potted LF C4MW 0275 AAAA A 6, 8
142A-3694-1300 120 VAC T t/c 135°C High limit Automatic Reset 3A Relay Fixed Potted LF C4NW 0135 AAAA A 6, 8
142A-3694-1400 120 VAC T t/c 275°F On/Off Heat 3A Relay Fixed Potted CF C4MH 0275 AAAA A 6, 8
142A-3694-1400 120 VAC T t/c 135°C On/Off Heat 3A Relay Fixed Potted CF C4NH 0135 AAAA A 6, 8
142A-3694-2200 230 VAC T t/c 275°F High limit Manual Reset 3A Relay Fixed Potted LF E4MU 0275 AAAA A 6, 8
142A-3694-2200 230 VAC T t/c 135°C High limit Manual Reset 3A Relay Fixed Potted LF E4NU 0135 AAAA A 6, 8
142A-3694-2300 230 VAC T t/c 275°F High limit Automatic Reset 3A Relay Fixed Potted LF E4MW 0275 AAAA A 6, 8
142A-3694-2300 230 VAC T t/c 135°C High limit Automatic Reset 3A Relay Fixed Potted LF E4NW 0135 AAAA A 6, 8
142A-3694-2400 230 VAC T t/c 275°F On/Off Heat 3A Relay Fixed Potted CF E4MH 0275 AAAA A 6, 8
142A-3694-2400 230 VAC T t/c 135°C On/Off Heat 3A Relay Fixed Potted CF E4NH 0135 AAAA A 6, 8
142A-3695-1200 120 VAC K t/c 572°F High limit Manual Reset 3A Relay Fixed Potted LF C4KU 0572 AAAA A 6, 8
142A-3695-1200 120 VAC K t/c 300°C High limit Manual Reset 3A Relay Fixed Potted LF C4LU 0300 AAAA A 6, 8
142A-3695-1300 120 VAC K t/c 572°F High limit Automatic Reset 3A Relay Fixed Potted LF C4KW 0572 AAAA A 6, 8
142A-3695-1300 120 VAC K t/c 300°C High limit Automatic Reset 3A Relay Fixed Potted LF C4LW 0300 AAAA A 6, 8
142A-3695-1400 120 VAC K t/c 572°F On/Off Heat 3A Relay Fixed Potted CF C4KH 0572 AAAA A 6, 8
