Installation and wiring – Watlow EZ-ZONE PM Express User Manual
Page 4
EZ-ZONE PM Express (PID)
• 4 •
Install and Wire
Installation and Wiring
1/32 DIN (PM3) Recommended Panel Spacing
Side
Front
Top
15.9 mm
(0.63 in)
101.6 mm
(4.00 in)
31.2 mm
(1.23 in)
53.3 mm
(2.10 in)
30.9 mm
(1.22 in)
45.2 mm
(1.78 in)
22.4 mm
(0.88 in)
21.6 mm
(0.85 in)
21.6 mm
(0.85 in)
panel thickness 1.53 to 9.52 mm
(0.060 to 0.075 in)
1/32 DIN (PM3) Dimensions
