EZ-ZONE PM Express (PID) • 22 • Setup Menu
‰
[`loC]
Lockout Menu
[`SEn]
Sensor Type
[`Lin]
Linearization
[``t;C]
Thermistor Curve
[``r;r]
Resistance Range
[`deC]
Decimal
[`C_F]
Display Units
[`r;lo]
Range Low
[`r;hi]
Range High
[`fn1]
Function Output 1
[`o;ty]
Output Type
[`fn2]
Function Output 2
[`h;ag]
Heat Algorithm
[`h;sC]
Hysteresis (Heat & Cool)
[`C;Ag]
Cool Algorithm
[`A;ty]
Alarm Type
[`A;hy]
Alarm Hysteresis
[`A;lg]
Alarm Logic
[`A;lA]
Alarm Latching
[`A;bl]
Alarm Blocking
[`A;si]
Alarm Silencing
[A;dsp]
Alarm Display
[``rp]
Ramp Action
[`r;rt]
Ramp Rate
[`s;lo]
Scale Low
[`s;hi]
Scale High
[o;hi1]
Power Scale High Output 1
[o;hi2]
Power Scale High Output 2
[`Ad;s]
Zone Address
Setup Menu
To enter the Setup Menu push and hold the
up and down arrow keys for approximately
3 seconds. Once there, push the green
advance key to scroll through to the prompt
of choice and then use the up and down
arrow keys to change the range. At any
point within the Setup menu to return to the
default display push the Infinity ˆ key.
Setup Menu
Display Parameter Name Description
[LoC]
[LoC]
Lockout Menu
Set the security clearance level. The user
can access the selected level and all lower
levels.
Appears if: Always
[Sen]
[ SEn]
Sensor Type
Set the analog sensor type to match the
device wired to this input.
Appears if: Always
[Lin]
[ Lin]
Linearization
Set the linearization to match the thermo-
couple type wired to this input.
For example, select [```H] for a type K
thermocouple.
Appears if: Sensor Type is set to Thermo-
couple.
[``t;C]
[ t.C]
Thermistor Curve
Select a curve to apply to the thermistor
input.
[``r;r]
[ r.r]
Resistance Range
Set the maximum resistance of the thermis-
tor input.
[`dEC]
[ dEC]
Decimal
Set the precision of the displayed value.
Appears if: Always
[`C_F]
[ C_F]
Display Units
Select which units will be displayed.
Appears if: Always
[r;Lo]
[ r.Lo]
Range Low
For process signals, this value scales the units
to minimum electrical units (0 volts or 4 mA)
Appears if: Always
[r;hi]
[ r.hi]
Range High
For process signals, this value scales the
units to maximum electrical units (10 volts
or 20 mA)
Appears if: Always
