EZ-ZONE PM Express (PID) • 24 • Setup Menu
Setup Menu
Display Parameter Name Description
[`fn1]
[ fn1]
Function of Output 1
Select which function will drive this output.
Appears if: If output 1 is ordered
[`o;ty]
[ o.ty]
Output Type
Select whether the process output will operate
in volts or milliamps.
Appears if: A process output (PM _ C _ F _-_
AAAB _ _)
[`fn2]
[ fn2]
Function of Output 2
Select which function will drive this output.
Appears if: If output 2 is ordered
[`h;Ag]
[ h.Ag]
Heat Algorithm
Set the heat control method.
Appears if: Output 1 or 2 set to heat
[`hSC]
[ hSC]
Hysteresis (Heat & Cool)
Set the control switching hysteresis for on-
off control. This determines how far into the
“on” region the process value needs to move
before the output turns on.
Appears if: Heat or Cool Algorithm is set to
On-Off.
[`C;Ag]
[ C.Ag]
Cool Algorithm
Set the cool control method.
Appears if: If Output 1 or 2 is set to cool
[`A;ty]
[ A.ty]
Alarm Type
Select how the alarm will or will not track the
set point.
Appears if: Always
[`A;hy]
[ A.hy]
Alarm Hysteresis
Set the hysteresis for an alarm. This deter-
mines how far into the safe region the process
value needs to move before the alarm can
be cleared.
Appears if: When alarm type is set to process
or deviation alarm
[a;lg]
[A.Lg]
Alarm Logic
Select what the output condition will be during
the alarm state.
Appears if: Always
‰
[`loC]
Lockout Menu
[`SEn]
Sensor Type
[`Lin]
Linearization
[``t;C]
Thermistor Curve
[``r;r]
Resistance Range
[`deC]
Decimal
[`C_F]
Display Units
[`r;lo]
Range Low
[`r;hi]
Range High
[`fn1]
Function Output 1
[`o;ty]
Output Type
[`fn2]
Function Output 2
[`h;ag]
Heat Algorithm
[`h;sC]
Hysteresis (Heat & Cool)
[`C;Ag]
Cool Algorithm
[`A;ty]
Alarm Type
[`A;hy]
Alarm Hysteresis
[`A;lg]
Alarm Logic
[`A;lA]
Alarm Latching
[`A;bl]
Alarm Blocking
[`A;si]
Alarm Silencing
[A;dsp]
Alarm Display
[``rp]
Ramp Action
[`r;rt]
Ramp Rate
[`s;lo]
Scale Low
[`s;hi]
Scale High
[o;hi1]
Power Scale High Output 1
[o;hi2]
Power Scale High Output 2
[`Ad;s]
Zone Address
Setup Menu
To enter the Setup Menu push and hold the
up and down arrow keys for approximately
3 seconds. Once there, push the green
advance key to scroll through to the prompt
of choice and then use the up and down
arrow keys to change the range. At any
point within the Setup menu to return to the
default display push the Infinity ˆ key.
Range (Defaults are shown bold)
[`oFF]
Off, [CooL] Cool, [hEAt] Heat, [ALM] Alarm
[uoLt]
Volts
[`MA]
Milliamps
[`oFF]
Off, [CooL] Cool,
[hEAt] Heat, [ALM] Alarm
[`oFF]
Off, [`Pid] PID
[on;of]
On-Off
0 to 9,999.000°F or units
0 to 5,555.000°C
Units, 3.0°F or 2.0°C
[`oFF]
Off, [`Pid] PID
[on;of]
On-Off
[`oFF]
Off, [PR;AL] Process Alarm
[dE;AL]
Deviation Alarm
0.001 to 9,999.000°F or units
0.001 to 5,555.000°C
Units, 1.0°F or 1.0°C
[`a;lC] Close on Alarm
[`a;lo]
Open on alarm
