HMI5000L Installation Guide 15

1010-1018 Rev 01 www.maplesystems.com

2. Set the HMI in the panel cutout and hold it in place until all

clamps are in position.

3. Tighten the screw clamps in an even pattern until all are

uniformly snug.

Caution: Do not over-tighten the screws beyond snugness or

you may damage the housing or warp the overlay.

REINSTALLATION:

If, at any time, you are required to reinstall an HMI into a panel, be

aware that the gasket will take a ‘set’ to the panel and may no longer

provide an adequate NEMA 4 seal. Therefore, for best results, we

recommend that you replace the gasket if reinstallation is required.

Configuration Wiring

To configure the HMI using the EZwarePlus software, you will need the

correct configuration cable for your HMI. Please refer to the following

table for configuration (download) cable requirements.

HMI Model

Ethernet

Configuration Cable

(Crossover)

P/N 7431-0104

USB

Configuration

Cable

P/N 7431-0115

HMI5043L, HMI5070L,
HMI5100L

X

HMI5070NL

X

HMI5121XL, HMI5150XL

X

X

Ethernet

If using a switch or router between the PC and the HMI, use a straight-

through or crossover cable as required by the switch or router.
