HMI5000L Installation Guide 13
1010-1018 Rev 01 www.maplesystems.com
3. Install the power supply wires as follows (with colors shown for
Maple Systems cable P/N 6030-0009):
Color Power Supply HMI
Red +Output/+24V DC +24 V
Black
–Output/+24V DC return
GND
Shield Case ground
FG or
NOTE: The power connector on the HMI5000L Series uses a 3-position
terminal block with screw-down clamps. Lugs are not required.
Panel Preparation
A metal panel or mounting surface with a minimum thickness of 15
gauge (0.059 in/3.3 mm) if cold-rolled steel or hardened steel, or 10
gauge (0.101 in/2.6 mm) if aluminum alloy (6061-T6 preferred) is
required. Thinner panels or surfaces may bow between the mounting
clamps and not form a seal with the gasket. Make sure all supplied
mounting clamps are used and that the panel does not flex or bow more
than 0.010 in. to ensure a proper seal.
The HMI should be mounted into a panel with a depth of at least 4 in.
(105 mm). Allow a clearance of at least 1 in. (25 mm) on each side for
mounting hardware. Consider proper clearance for cable connections
when mounting.
NOTE: Cutout dimensions for each particular HMI model are readily
available for download from the Support Center-Dimensional Drawings
section of the Maple Systems website.
The area of the panel or mounting surface where the gasket comes into
contact must be flat and free of scratches, pits, and other features that
