3 OMI5000 Series Installation Guide
1010-1013 Rev 01 www.maplesystems.com
Maple Systems liability is limited to the repair or replacement of the
Product only, and not costs of installation, removal, or damage to user’s
property or other liabilities. If Maple Systems is unable to repair or
replace a nonconforming Product, it may offer a refund of the amount
paid to Maple Systems for such Product in full satisfaction of its
warranty obligation. Maximum liability of Maple Systems is the cost of
the Product.
Information furnished by Maple Systems, Inc., is believed to be accurate
and reliable. However, no responsibility is assumed by Maple Systems
for the use of this information, or for any infringements of patents or
other rights of third parties which may result from its use. No license is
granted by implication, or otherwise, under any patent or patent rights of
Maple Systems, Inc. Maple Systems retains the right to revise or change
its products and documentation at any time without notice.
Installation of OMIs
CE Compliance
The OMI5000 Series Open HMIs have been tested to conform to
European CE requirements, which meet or exceed the noise emissions
and immunity requirements as set forth in the EN55022 (Emissions) and
EN55024 (Immunity) standards. The products are designed to withstand
electrical noise in harsh industrial environments. They also conform to
requirements that limit electrical emissions. However, this does not
guarantee that the products will be totally immune from possible
malfunction in cases where severe electrical noise occurs. Therefore, we
strongly recommend that you follow the guidelines outlined in this guide
for proper wire routing and grounding to insure the proper operation of
your Open HMI.
NEMA Rating
The OMI5000 Series is rated for NEMA 4/12 (indoor) or IP65
installations. This means that when the OMI is properly mounted to a
NEMA 4 panel or other NEMA 4 rated enclosure, the front enclosure of
