Using the NetLinx Module
70 Metreau Entry Communicators
Intercom Demo page
The module for duplex intercom capable panels includes user pages. While you can create your own
intercom directory page (see the Creating Intercom Pages section on page 68), it is possible to use the
panel with the page shown in FIG. 53.
FIG. 53 Sample Intercom Page
Sample Intercom Page
No. Name Description Channel
Port:Code
Address
Port:Code
Level
Port:Code
1 Room Name The name of the panel as it
appears in other intercom
directories. See Naming a
panel section on page 66. 0:265
2 Page All Pages all connected intercom
panels. 1:6
3 Place Call Initiates an intercom call to a
panel. 1:7
4 End Ends an intercom call to a
panel. 1:8
5 Call Privacy Off Toggles the privacy option of
the intercom. When enabled,
other panels cannot contact the
panel. 1:9
6 Door Privacy Off Toggles the privacy option of
the doorbell. When enabled,
doorbells in the system cannot
contact the panel. 1:36
7 Monitor Enables the panel to monitor
another room’s intercom panel. 1:19
8 Panel Directory Room Name The name of a panel in the
intercom directory. You can call
the panel, enact privacy
against the panel and monitor
the panel.
1:1 1:1
1
2
3
4
5
6
7
13 18 23
14 19 24
15 20 25
16 21 26
17 22 27
28
29
30
31
32
33
8
9
10
11
12
