Metreau Entry Communicators

MET-ECOM Specifications (Cont.)

Microphone:

• -40 dB sensitivity, built-in echo cancellation (telephone quality)
• Full duplex communication
• VoIP Telephony

Rear Panel Components:

• Camera Viewing Angle Adjustment
• Ethernet Port - 10/100 Ethernet with PoE. LEDs show communication

activity, connection status, speeds, and mode information:

SPD (speed) - Green LED lights On when the connection speed is 100
Mbps and turns Off when the speed is 10 Mbps.
L/A (link/activity) - Orange LED lights On when the Ethernet cables are
connected and terminated correctly, and blinks when receiving Ethernet
data packets.

• ID/Reset pushbutton: Push to set the NetLinx ID (Device only) assignment

for the device. Push and hold for at least 10 seconds to reset to factory
default settings.

• Status LED: Green LED provides an indication of both the system status

and communication status with the target Master. 1 blink every 5 seconds
indicates there is currently active communication between the Metreau unit
and a target Master.

• 2 Multi-Purpose I/Os (5V): 2-channel binary I/O ports for contact closure

with each input being capable of voltage sensing. Input format is software
selectable with interactive power sensing for IR ports.

• 2 Low Voltage Relays (1A contact): 2-channel single-pole single throw

relay ports with each relay being independently controlled and supporting
up to 2 independent external relay devices.

Dimensions (HWD):

• 5.364” x 3.594” x 1.559”
• 13.62 cm x 9.13 cm x 3.96 cm
Note: Refer to the Mounting Specifications section on page 16 for mounting
dimensions.

Weight:

0.90 lbs (0.408 kg)

Operating Environment:

-22° to 140° F (-30° to 60° C)

Mounting:

• The MET-ECOM is installed in one of two ways:
• 4 screws for hard surface mounting
• 2 expansion clips for pressure mounting

Colors Available:

• Black MET-ECOM-BK (FG2180-01-BK)
• White MET-ECOM-WH (FG2180-01-WH)
• Polished Brass MET-ECOM-PB (FG2180-01-PB)
• Antique Brass MET-ECOM-AB (FG2180-01-AB)
• Stainless Steel MET-ECOM-SS (FG2180-01-SS)
• Brushed Pewter MET-ECOM-BP (FG2180-01-BP)

Included Accessories:

• Installation Kit (FG039-12) - includes front mount flange, 4 installation

screws (#4-40 x 3.12), 2 Phoenix connectors (female, 3.5mm) and a
Ferrite clip.

Other AMX Equipment:

• PS-POE-AF Power-over-Ethernet (PoE) power supply (FG423-80)
• NXA-ENET24 Managed Ethernet Switch (FG2178-60)
• NXA-ENET24PoE Managed Ethernet Switch, Power Over Ethernet

(FG2178-61)

• Conduit Box Assembly (FG039-12)
• CB-MET-ECOMS Surface Mount Box (FG039-14-S/B)

Certifications:

• FCC Class B
• CE
• IEC60950
• RoHS
