Using the Configuration Manager
30 Metreau Entry Communicators
Command Buttons
The Configuration Manager is divided into four primary sections, indicated by four command buttons
across the top of the main page (FIG. 26):
Summary: The Summary of Device page is the page that is displayed when the Configuration
Manager is accessed. Use the this page to view a summary of settings for this Metreau Entry
Communicator (see the Summary of Settings Page section on page 31).
Configuration: Click to access the IP Settings, NetLinx Settings and User Settings options
(see the Configuration Page section on page 33).
Utilities: Click to access the Utilities page. Use the options on this page to upload, change,
and display images on the Metreau Entry Communicator (see the Device Utilities
Page section on page 37).
Audio Video: Click to access the Audio/Video page. Use the options on this page to configure
Audio, Video and Display settings (see the Audio/Video Page section on page 43).
Accessing the Configuration Manager
From any PC that has access to the LAN that the Metreau Entry Communicator resides on:
1. Open a web browser and type the IP Address of the target Master in the browser’s Address Bar.
2. Press Enter to access the Configuration Manager for the specified device.
3. If prompted for a User Name and Password (FIG. 27), enter the defaults:
Default User Name = Admin
Default Password = 1988
4. The initial view is the Summary page (FIG. 25).
FIG. 26 Configuration Manager Command Buttons
FIG. 27 Authentication Required dialog
