Raven CDMA User Guide for Verizon, version 2.23 49
• Humidity: 5%-95% Non-condensing
Power Management:
• Low power consumption
• Dormant connection (idle for 10-20 seconds): at 12 VDC
• Input Voltage: 10 VDC to 28 VDC
• Input Current: 20 mA to 350 mA
• Low power mode: at 12 VDC
Power consumption
Serial Port Pin-outs
The cable between the modem and a computer or other serial device needs to be
wired straight-through (pin 1 goes to pin 1, pin 2 to pin 2, etc).
Modem Idle Transmitting
Raven C3211 50 mAh 200-300 mAh
Raven C3210 50 mAh 250-300 mAh
