A-1 GENERAL DESCRIPTION
MAGNUM® PRO THRU THE ARM ROBOTIC TORCH
A-1
GENERAL DESCRIPTION
The Magnum® Pro product line is designed for heavy
duty applications and possesses market leading rat-
ings and simplicity in maintenance.
The Magnum® Pro Thru the Arm Robotic Torch has
been designed to meet specifications for welding with
steel electrode using the GMAW (gas metal arc weld-
ing) and gas-shielded FCAW (flux-cored arc welding)
processes.
The Magnum® Pro Thru the Arm Robotic Torch is
rated for 550 amps at 100% duty cycle with 100%
CO2 shielding gas. It is rated at 375 amps at 100%
duty cycle with mixed gas.
The Thru-arm Torch is designed for use with the
Fanuc
® ARC Mate ® 100iC, 100iC/6L, 120iC and
120iC/10L. Models are factory equipped with a feeder
connector for most Lincoln robot-mounted feeders (i.e.
4R90, 4R100 4R220).
• Do not touch electrically live parts
such as output terminals or inter-
nal wiring.
------------------------------------------------------------------------
RECOMMENDED PROCESSES AND
EQUIPMENT
RECOMMENDED PROCESSES
• GMAW, GMAW-P, GMAW-STT, FCAW, FCAW-SS
PROCESS LIMITATIONS
• This product is not recommended for submerged
arc welding.
EQUIPMENT LIMITATIONS
• Robots:
• K2917-100iC, K2917-100iC/6L, K2917-120iC and K2917-
120iC/10L, K3353-100iC, K3353-100iC/6L, K3353-120iC,
K3353-120iC/10L, K3353-100iCW, K3353-100iC/6LW, K3353-
120iCW, K3353-120iC/10LW, K3359-100iC, K3359-100iC/6L,
K3359-120iC, K3359-120iC/10L, K3359-100iCA, K3359-
100iC/6LA, K3359-120iCA, K3359-120iC/10LA, K3359-
100iCW, K3359-100iC/6LW, K3359-120iCW, K3359-
120iC/10LW
are specifically designed to be used with
the Fanuc
®
ARC Mate
® 100iC, 100iC/6L, 120iC
and 120iC/10L respectively. Because the cables
are routed through the robot and have a precise
length, these welding torches cannot be used on
any other model robot.
• Activation limits are as follows: J6 Axis [+/-270º]
• Wirefeeders:
• K2917, K3353 and K3359 Series are not compati-
ble with the Power Feed 10R. They are designed
only to work with “nested” wire feeders such as
the 4R90, 4R100 and 4R220.
• It is not recommended that the K2917, K3353 or
K3359 Series be used with any non robot-mount-
ed wirefeeder.
COMMON EQUIPMENT PACKAGES
The available replacement parts for the Thru-arm are
shown in Table A.1.
• KP2918/KP2919 series gooseneck are used in
K2917 torches.
• KP3354/KP3355 series goosneck are used in
K3353 and K3359 torches.
TABLE A.1
MAGNUM ® PRO THRU THE ARM
REPLACEMENT EQUIPMENT
Product Number Description
KP2918-22 Tregaskiss ® 22° TCP Gooseneck
KP2918-45 Tregaskiss ® 45° TCP Gooseneck
KP2919-22 Binzel ® 22° TCP Gooseneck
KP2919-45 Binzel ® 45° TCP Gooseneck
KP2919-180 Binzel ® 180° TCP Gooseneck
KP3354-22 Tregaskiss ® 22° TCP Gooseneck
KP3354-45 Tregaskiss ® 45° TCP Gooseneck
KP3355-22 Binzel ® 22° TCP Gooseneck
KP3355-45 Binzel ® 45° TCP Gooseneck
KP3355-180 Binzel ® 180° TCP Gooseneck
KP2920-1 Breakaway Disc
KP3066-100iC Cable Assembly, Fanuc ® 100iC
KP3066-100iC/6L Cable Assembly, Fanuc ® 100iC/6L
KP3066-120iC Cable Assembly, Fanuc ® 120iC
KP3066-120iC/10L Cable Assembly, Fanuc ® 120iC/10L
WARNING
