General description, Robot activation limits – Lincoln Electric IM10071 MAGNUM PRO THRU THE ARM ROBOTIC TORCH User Manual
Page 11
A-4
GENERAL DESCRIPTION
MAGNUM® PRO THRU THE ARM ROBOTIC TORCH
A-4
MAGNUM® PRO THRU THE ARM FOR 120iC/10L ROBOT
550 AMPS AT 100% DUTY CYCLE WITH CO
2
GAS
375 AMPS AT 100% DUTY CYCLE WITH MIXED GAS
Gun Cable
Length (m)
4 ft.
(1.2)
4 ft.
(1.2)
4 ft.
(1.2)
Wire Size
Range
in. (mm)
.035 (0.9)
5/64 (2.0)
.035 (0.9)
5/64 (2.0)
.035 (0.9)
5/64 (2.0)
Contact Tips
Standard
Duty
KP2745-035R
KP2745-045R
KP2745-040
Gas Diffuser
Assembly
KP2747-1
KP2747-1
Gas
Nozzle
KP2743-1-62R
KP2743-1-62R
Insulator
KP2773-1
KP2773-1
Cable Liner
KP45-3545-15
KP45-3545-6
Gun Tube 45°
KP2919-45
KP3355-45
Jump Liner
KP3364-1
“W” ONLY
Description
Product
Number
K2917-120iC/6L
K3353-120iC/10L
K3353-120iC/10LW
K3011-120iC/6L
(Ready Pak)
K3359-120iC/10L
K3359-120iC/10LA
K3359-120iC/10LW
(Ready Pak)
J6 AXIS: +/- 270º
ROBOT ARM
ROBOT ACTIVATION LIMITS
