A-2 INSTALLATION
POWER WAVE ® ADVANCED MODULE
A-2
saFety PreCautions read
this
entire installation section before you start installa-
tion.
eLeCtrIC SHoCK can kill.
•turn off the power source at the
disconnect switch before connect-
ing or working inside of the equip-
ment.
•only a qualified electrician should
install and connect the advanced
module.
------------------------------------------------------------------------
eLeCtromagnetIC ComPatIBILItY (emC)
The EMC classification of the Power Wave ®
AdvancedModuleisIndustrial,ScientificandMedical
(ISM)group2,classA.ThePowerWave
® Advanced
Moduleisforindustrialuseonly.(SeeprintL10093for
furtherdetails).
Locate the Advanced Module away from radio con-
trolled machinery. The normal operation of the
AdvancedModulemayadverselyaffecttheoperation
ofRFcontrolledequipment,whichmayresultinbodily
injuryordamagetotheequipment.
LoCatIon anD mountIng
(See Figure a.1)
MounttheAdvancedModuledirectlytothebottomof
a compatible Power Wave
® “S” series power source
utilizing the quick lock mechanism as shown. The
Advanced Module will operate in harsh environments
and can be used outdoors. Even so, it is important
that simple preventative measures are followed in
ordertoassurelonglifeandreliableoperation.
•Themachinemustbelocatedwherethereisfreecir-
culationofcleanairsuchthatmovementintoandout
ofthelouverswillnotberestricted.
•Dirt and dust that can be drawn into the machine
should be kept to a minimum. The use of air filters
on the air intake is not recommended because nor-
mal air flow may be restricted. Failure to observe
these precautions can result in excessive operating
temperaturesandnuisanceshutdown.
•Keep the machine dry. Shelter from rain and snow.
Donotplaceonwetgroundorinpuddles.
•Do not mount the Power Wave ® “S” series power
source and Advanced Module combination over
combustiblesurfaces.Wherethereisacombustible
surface directly under stationary or fixed electrical
equipment,thatsurfaceshallbecoveredwithasteel
plateatleast.060”(1.6mm)thick,whichshallextend
not less than 5.90” (150mm) beyond the equipment
onallsides.
WARNING
FIgure a.1
