AFL2-W10A-N28 Panel PC
Page 62
4.3.7 H/W Monitor
The H/W Monitor menu (
8
BIOS Menu 10) shows the operating temperatures.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
CPU temperature :+37 °C
System temperature :+36 °C
Environment Temperature : +30 °C
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 10: Hardware Health Configuration
Î Hardware Health Status
The following system parameters and values are shown. The system parameters that are
monitored are:
ƒ CPU Temperature
ƒ System Temperature
ƒ Environment Temperature
4.3.8 Serial Port Console Redirection
The Serial Port Console Redirection menu (
8
BIOS Menu 14) allows the console
redirection options to be configured. Console redirection allows users to maintain a
system remotely by re-directing keyboard input and text output through the serial port.
