AFL2-W10A-N28 Panel PC

Page 40

Figure 3-26: Audio Connector

Step 3:

Check audio clarity. Check that the sound is coming through the right speakers

by adjusting the balance front to rear and left to right.

3.12.2 DisplayPort Connection

The DisplayPort connector transmits a digital signal to compatible DisplayPort display

devices such as a TV or computer screen. To connect the DisplayPort cable to the

AFL2-W10A-N28, follow the steps below.

Step 1:

Locate the DisplayPort connector. The location is shown in Chapter 3.

Step 2:

Align the connector. Align the DisplayPort connector with the DisplayPort port.

Make sure the orientation of the connector is correct.
