AFL2-W10A-N28 Panel PC
Page 118
Connector Type Label
EC debug connector 18-pin header CN1
HDD connector 20-pin connector JSATA1
Hot key connector 9-pin wafer HOTKEYCN1
Hot key LED connector 8-pin wafer HOTKEYLEDCN1
LED indicator connector 16-pin header LEDCN1
LVDS connector 20-pin crimp LCD1
LVDS backlight connector 5-pin wafer INVERTER1
microSD connector 5-pin wafer MICRO_SD1
Mini USB connector 4-pin wafer MINI_USB1
PCIe Mini card slot PCIe Mini card slot MINI_PCIE1
Power button connector 2-pin wafer PW_BT1
RFID COM connector 4-pin wafer RFID_COM1
RFID USB connector 4-pin wafer RFID1
SATA LED connector 2-pin wafer JP5
SO-DIMM connector SO-DIMM connector DIMM1
Speaker connector 4-pin wafer SPKR1
SPI Flash connector 6-pin wafer SPI1
SPI Flash connector (EC) 6-pin wafer JSPI2
Touch panel connector (1) 9-pin wafer TS1
Touch panel connector (2) 4-pin wafer TOUCH1
Type K thermocouple connector 2-pin wafer K_TYPE1,
K_TYPE2
Webcam USB connector 4-pin wafer CAMERA1
Webcam microphone connector 4-pin wafer WEBCAM_DMIC1
Table 7-1: Peripheral Interface Connectors
