AFL2-W10A-N28 Panel PC

Page 8

ƒ 1 x RS-422/485 RJ-45 connector

ƒ 2 x USB 2.0 connectors

ƒ 2 x USB 3.0 connectors

Figure 1-6: Bottom Panel

1.2.4 Left Side Panel

The left side panel of the AFL2-W10A-N28 has a temperature sensor (

8

Figure 1-7).

Figure 1-7: Left Side Panel
