AFL2-W10A-N28 Panel PC

Page 113

Figure 6-7: Attaching the Antennas

Step 11:

Replace the internal cover and secure it to the chassis using the previously

removed retention screws.

Step 12:

Replace the back cover and secure it using the previously removed retention

screws.

Step 0:

6.6 Reinstalling the Covers

WARNING:

Failing to reinstall the covers may result in permanent damage to the

system. Please make sure all coverings are properly installed.

When maintenance procedures are complete, please make sure all the covers are

replaced, including the following:
