AFL-F08A-N270 Panel PC
Page 40
Step 2: Align the connectors. Align the USB device connector with one of the
connectors on the bottom panel.
Figure 3-24: USB Device Connection
Step 3: Insert the device connector. Once aligned, gently insert the USB device
connector into the onboard connector.
3.10 Powering On the System
WARNING:
Make sure a power supply with the correct input voltage is being fed
into the system. Incorrect voltages applied to the system may cause
damage to the internal electronic components and may also cause
injury to the user.
To power-on the AFL-F08A-N270 using the function key, please follow the steps below:
Step 1: Connect a power source to the power connector on the bottom panel. All of the
function keys on the front panel illuminate with low-intensity light.
