AFL-F08A-N270 Panel PC
Page 87
6.2.5 Battery Connector (BT1)
6.2.6 CompactFlash® Type II Slot (CF1)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GROUND1 26 CD1
2 DATA 3 27 DATA 11
3 DATA 4 28 DATA 12
4 DATA 5 29 DATA 13
5 DATA 6 30 DATA 14
6 DATA 7 31 DATA 15
7 CE 32 CE2
8 A10 33 VS1
9 OE 34 IOR
10 A9 35 IOW
11 A8 36 WE
12 A7 37 IRQ
13 VCC1 38 VCC2
14 A6 39 CSEL
15 A5 40 VS2
16 A4 41 RESET
17 A3 42 WAIT
18 A2 43 INPACK
19 A1 44 REG
20 A0 45 BVD2
21 DATA 0 46 BVD1
22 DATA 1 47 DATA 8
23 DATA 2 48 DATA 9
PIN NO. DESCRIPTION
1 Battery +3.3V
2 GND
Table 6-6: Battery Connector (BT1) Pinouts
