AFL-F08A-N270 Panel PC
Page 95
11 +3.3Vsus 12 ACT-1
13
LAN1_LINK1000
+3.3Vsus
14
LAN1_LINK100
+3.3Vsus
15 GND 16 GND
17 N/A 18 N/A
Table 6-25: Ethernet Connector (LAN1, LAN2) Pinouts
6.3.2 Power Connector (CN5)
PIN NO. DESCRIPTION
1 GND
2 GND
3 VCC12_IN
Table 6-26: Power Connector (CN5) Pinouts
6.3.3 RS-232 Serial Ports (COM1)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 NDCD1 2 NRX1
3 NTX1 4 NDTR1
5 GND 6 NDSR1
7 NRTS1 8 NCTS1
9 COM_RI1 10 GND
Table 6-27: RS-232 Serial Ports (COM1) Pinouts
6.3.4 RS-422/485 Serial Port (COM3)
PIN NO. RS-232 RS-422 RS-485
1 NDCDB TX- D-
2 NRXDB TX+ D+
3 NTX3
