AFL-F08A-N270 Panel PC
Page 85
Connector Type Label
CRT connector 10-pin header CN4
DIO connector 10-pin header DIO1
HDD power connector 4-pin wafer CN1
LED indicator and button connector 10-pin header JP2
LVDS backlight connector 6-pin wafer INVERTER1
MCU connector 8-pin header
10-pin header
TS2
JP7
PCIe Mini card slot PCIe Mini card slot CN2
RFID connector 10-pin header JP8
SATA connector SATA connector SATA1
SO-DIMM connector SO-DIMM connector DIMM1
SPI Flash connector 8-pin header JSPI1
Touch panel connector (solder side) 9-pin wafer TS1
TTL panel connector (solder side) 40-pin FPC connector CN7
JUSB connector 4-pin header JUSB1
USB connector 8-pin header USB1
USB connector 4-pin wafer USB2
USB connector 4-pin wafer USB4
Table 6-1: Peripheral Interface Connectors
6.2.1 Audio Line-out Connector (CN8)
PIN NO. DESCRIPTION
1 SPK_R
2 AMP_R
3 AMP_L
4 SPK_L
Table 6-2: Audio Line-out Connector (CN8) Pinouts
