AFL-F08A-N270 Panel PC
Page 91
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
37 RESERVED 38 USBD+
39 RESERVED 40 GND
41 RESERVED 42 LED_WWAN#
43 RESERVED 44 LED_WLAN#
45 RESERVED 46 LED_WPAN#
47 RESERVED 48 1.5 V
49 RESERVED 50 GND
51 RESERVED 52 VCC3
Table 6-15: PCIe Mini Card Slot (CN2) Pinouts
6.2.15 RFID Connector (JP8)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 2 +5V
3 4 GND
5 6 RX2
7 8 TD2
9
For COM1 Pin 9
setting
10 RFID_INT
2 10
y y y y y
y y y y y
1 9
Table 6-16: RFID Connector (JP8) Pinouts
6.2.16 SATA Connector (SATA1)
PIN NO. DESCRIPTION
1 GND
2 TX+
3 TX-
4 GND
5 RX-
6 RX+
7 GND
Table 6-17: SATA Connector (SATA1) Pinouts
