AFL-F08A-N270 Panel PC
Page 93
17 TFT_B2 37 GND
18 TFT_B1 38 DOTCLK
19 TFT_B0 39 GND
20 GND 40 GND
Table 6-19: TTL Panel Connector (CN7) Pinouts
6.2.19 JUSB Connector (JUSB1)
6.2.20 USB Connector (USB1)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 +5Vsus 2 GND
3 D0F- 4 D0F+
5 D0F+ 6 D0F-
7 GND 8 +5Vsus
2 8
y y y y
y y y y
1 7
Table 6-21: USB Connector (USB1) Pinouts
6.2.21 USB Connector (USB2)
PIN NO. DESCRIPTION
1 +5Vsus
2 D6F-
3 D6F+
4 GND
Table 6-20: JUSB Connector (JUSB1) Pinouts
PIN NO. DESCRIPTION
1 USB Power (selected by JP15)
2 D2F-
3 D2F+
4 GND
Table 6-22: USB Connector (USB2) Pinouts
