AFL-F08A-N270 Panel PC
Page 21
3.7.2 Preconfigured Jumpers
WARNING:
Do not change the settings on the jumpers in described here. Doing so
may disable or damage the system.
The following jumpers are preconfigured for the AFL-F08A-N270. Users should not
change these jumpers (
77
Table 3-2 ). The jumper settings of the preconfigured jumpers are
listed in Chapter 6 for reference.
Jumper Name Label Type
Backlight voltage selection J_BL1 3-pin header
Inverter power selection JP12 6-pin header
LVDS voltage selection J_VLVDS1 3-pin header
MCU LCD type selection JP14 4-pin header
MCU PWM power selection JP13 3-pin header
Panel type and resolution J_LCD_TYPE1 10-pin header
Touchscreen selection J1 4-pin header
USB2 and USB4 power selection JP15 6-pin header
Table 3-2: Preconfigured Jumpers
3.7.3 AT/ATX Power Select Jumper Settings
Jumper Label: Switch
Jumper Type: Two-setting switch
Jumper Location: See
77
Figure 3-7
Set this switch to the required power setting.
