AFL-HM55 Series Panel PC
Page 55
4.3 Turn off the Power
WARNING:
Failing to turn off the system before opening it can cause permanent
damage to the system and serious or fatal injury to the user.
Before any maintenance procedures are carried out on the system, make sure the system
is turned off.
4.4 Replacing Components
4.4.1 Memory Module Replacement
The flat panel PC features two DDR3 dual-channel SO-DIMM sockets supporting a
system max of 8GB. If the memory module fails, follow the instructions below to replace
the memory module.
Step 1:
Remove the back cover. See Section 3.7.
Step 2:
Remove the internal aluminum back cover. See Section 3.8.
Step 3:
Remove four (4) retention screws securing the HDD bracket to the chassis. See
the following figure.
