AFL-HM55 Series Panel PC

Page 29

3.9.4 COM1 Pin 9 Setting

Jumper Label:

JP7 and JP8

Jumper Type:

6-pin header

Jumper Settings:

See Table 3-4 and Table 3-5

Jumper Location:

See 1Figure 3-8 and Figure 3-8

Two jumpers (JP7 and JP8) configure pin 9 on COM1 and COM3 DB-9 connectors. Pin 9

on the COM1 and the COM3 DB-9 connectors can be set as the ring (RI) signal, +5 V or

+12 V. The COM1 and COM3 Pin 9 Setting jumper selection options are shown in the

tables below.

JP7 Description

Short 1-2

COM1 RI +12 V

Short 3-4

COM1 RI Normal

Short 5-6

COM1 RI Pin +5 V

Table 3-4: COM1 Pin 9 Setting Jumper Settings

The JP7 jumper location is shown below.
