background image

AFL-HM55 Series Panel PC

Page 27

3.9.1 Access the Jumpers

To access the jumpers, please remove the back panel and the internal aluminum chassis

(see Section 3.7 and Section3.8).

3.9.2 Preconfigured Jumpers

WARNING:

Do not change the settings on the jumpers in described here. Doing so

may disable or damage the system.

The following jumpers are preconfigured for the AFL-HM55 Series. Users should not

change these jumpers (Table 3-2).

Jumper Name

Label

Type

MCU Detect LCD Type

JP3

4-pin header

MCU PWM Power

JP4

3-pin header

LCD Power Select

J_VLVDS1

6-pin header

Table 3-2: Preconfigured Jumpers

3.9.3 Clear CMOS Jumper

Jumper Label:

J_CMOS1

Jumper Type:

3-pin header

Jumper Settings:

See Table 3-3

Jumper Location:

See Figure 3-7

If the AFL-HM55 Series fails to boot due to improper BIOS settings, the clear CMOS

jumper clears the CMOS data and resets the system BIOS information. To do this, use the

jumper cap to close the pins for a few seconds then remove the jumper clip.
