ECN-780-Q67 Em b e d d e d S ys te m
P a g e 77
 Tem p eratu re o f Start [75]
WARNING:
Setting this value too high may cause the fan to rotate at full speed only
when the CPU is at a very high temperature and therefore cause the
system to be damaged.
The Temperature of Start option can only be set if the CPU Smart Fan control option is
set to Auto Mode. When the CPU Temperature is higher than Temperature of Start, the
fan will be rotate at full speed. To set a value, select the Temperature of Start option and
enter a decimal number between 0 and 127. The temperature range is specified below.
 Minimum Value: 0°C
 Maximum Value: 127°C
 Tem p eratu re o f Off [80]
WARNING:
Setting this value too high may cause the fan to speed up only when
the CPU is at a very high temperature and therefore cause the system
to be damaged.
The Temperature of Off option can only be set if the CPU Smart Fan control option is
set to Auto Mode. When the CPU Temperature is higher than Temperature of Off, the
fan will be speed up. To set a value, select the Temperature of Off option and enter a
decimal number between 0 and 127. The temperature range is specified below.
 Minimum Value: 0°C
 Maximum Value: 127°C
 Start PWM [30]
