 Processor Cores: Lists the number of the processor core
 Intel HT Technology: Indicates if Intel HT Technology is supported by the
CPU.
 Intel VT-x Technology: Indicates if Intel VT-x Technology is supported by the
CPU.
 Intel SMX Technology: Indicates if Intel SMX Technology is supported by the
CPU.
 L1 Data Cache: Lists the amount of data storage space on the L1 cache.
 L1 Code Cache: Lists the amount of code storage space on the L1 cache.
 L2 Cache: Lists the amount of storage space on the L2 cache.
 L3 Cache: Lists the amount of storage space on the L3 cache.
5.3.5 S ATA Co n fig u ra tio n
Use the SATA Configuration menu (BIOS Menu 8) to change and/or set the
configuration of the SATA devices installed in the system.
Aptio Setup Utility – Copyright (C) 2009 American Megatrends, Inc.
Advanced
SATA Configuration
SATA Mode [IDE Mode]
Serial-ATA Controller 0 [Compatible]
SATA Port1 WDC WD1600BEVT (160.0
SATA Port2
Not Present
(1) IDE Mode. (2) AHCI
Mode.
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
F1 General Help
F2 Previous Values
F3 Optimized
Defaults
F4
Save
ESC Exit
Version 2.00.1201. Copyright (C) 2009 American Megatrends, Inc.
BIOS Menu 8: IDE Configuration
 S ATA Mo d e [IDE Mo d e ]
Use the SATA Mode option to configure SATA devices as normal IDE devices.

IDE Mode D EFAULT Configures SATA devices as normal IDE device.
