NOVA-HM551 5.25" SBC
Page 17
RS-232/422/485 serial port connector 14-pin header COM6
Serial ATA (SATA) drive connector 7-pin SATA S_ATA1
Serial ATA (SATA) drive connector 7-pin SATA S_ATA2
Serial ATA (SATA) drive connector 7-pin SATA S_ATA5
Serial ATA (SATA) drive connector 7-pin SATA S_ATA6
SATA power connector 2-pin wafer SATA_PWR1
SATA power connector 2-pin wafer SATA_PWR2
SMBus connector 4-pin wafer SMB1
SPI Flash connector 8-pin wafer JSPI1
USB connector 8-pin header USB1
USB connector 8-pin header USB2
USB connector 8-pin header USB3
USB connector 8-pin header USB4
VGA connector 10-pin box header VGA1
Table 3-1: Peripheral Interface Connectors
3.1.3 External Interface Panel Connectors
The table below lists the connectors on the external I/O panel.
Connector Type Label
Ethernet connector RJ-45 LAN1
Ethernet connector RJ-45 LAN2
HDMI HDMI port HDMI1
HDMI HDMI port HDMI2
Table 3-2: Rear Panel Connectors
