5.4.1 North Bridge Configuration
Use the North Bridge Chipset Configuration menu (BIOS Menu 14) to configure the
Northbridge chipset.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Chipset
Memory Information
CPU Type
Clarksfield
Total Memory
2048 MB (DDR3 1333)
Memory Slot0
2048 MB (DDR3 1333)
Memory Slot2 0 MB (DDR3 1333)
CAS# Latency(tCL)
8
RAS# Active Time(tRAS) 24
Row Precharge Time(tRP) 9
RAS# to CAS# Delay(tRCD) 9
Write Recovery Time(tWR) 10
Row Refresh Cycle Timea(tRFC) 74
Write to Read Delay(tWTR) 5
Active to Active Delay 4
Read CAS# Precharge(tRTP) 5
Initate Graphic Adapter
[PEG/IGD]
IGD Memory [64M]
Select which graphics
controller to use as the
primary boot device.
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
F1 General Help
F2 Previous Values
F3 Optimized
Defaults
F4 Save
ESC Exit
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 14:North Bridge Chipset Configuration
Î Initiate Graphics Adapter [PEG/IGD]
Use the Initiate Graphics Adapter option to select the graphics controller used as the
primary boot device. Select either an integrated graphics controller (IGD) or a combination
of PCI graphics controller, a PCI express (PEG) controller or an IGD. Configuration
options are listed below:
ƒ IGD
ƒ PEG/IGD D EFAULT
