NOVA-HM551 5.25" SBC
Page 102
5.5 Boot
Use the Boot menu (BIOS Menu 17) to configure system boot options.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Main Advanced Chipset Boot Security Save & Exit
Boot Configuration
Quiet Boot [Enabled]
Bootup NumLock State [On]
Realtek 8111E PXE OpROM [Disabled]
Boot Option Priorities
Enables/Disables Quiet
Boot option
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
F1 General Help
F2 Previous Values
F3 Optimized
Defaults
F4 Save
ESC Exit
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 17: Boot
Î Quiet Boot [Enabled]
Use the Quiet Boot BIOS option to select the screen display when the system boots.
Î
Disabled Normal POST messages displayed
Î
Enabled D EFAULT OEM Logo displayed instead of POST messages
Î Bootup NumLock [On]
Use the Bootup NumLock BIOS option to specify if the number lock setting must be
modified during boot up.
Î
Off Does not enable the keyboard Number Lock automatically. To
use the 10-keys on the keyboard, press the Number Lock key
located on the upper left-hand corner of the 10-key pad. The
Number Lock LED on the keyboard lights up when the Number
Lock is engaged.
