5.4.3 Intel IGD SWSCI OpRegion
Use the Intel IGD SWSCI OpRegion menu to configure the video device connected to the
system.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Chipset
Intel IGD SWSCI OpRegion Configuration
DVMT/FIXED Memory
[Maximum]
Active LFP [Enable LVDS]
LCD Panel Type [Select by Panel ID]
Panel ID Resolution 1024x768 18bit
Select the DVMT/FIXED
Mode Memory size used by
Internal Graphics
Device.
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
F1 General Help
F2 Previous Values
F3 Optimized
Defaults
F4 Save
ESC Exit
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 16: Intel IGD SWSCI OpRegion
Î DVMT/FIXED Memory [Maximum]
Use the DVMT/FIXED Memory option to specify the maximum amount of memory that
can be allocated as graphics memory. Configuration options are listed below.
ƒ 128 MB
ƒ 256 MB
ƒ Maximum Default
Î Active LFP [Enable LVDS]
Use the Active LFP option to enable the LVDS connector. Configuration options are listed
below.
ƒ Disable LVDS
ƒ Enable LVDS D EFAULT
