KINO-9652 Mini-ITX SBC
Page 40
Serial port connector 14-pin header COM1
TPM connector 20-pin header TPM1
TV out connector 6-pin header TV1
USB connector (1) 8-pin header USB1
USB connector (2) 8-pin header USB2
Table 4-1: Peripheral Interface Connectors
The KINO-9652 also has two on-board LED indicators:
PWR_LED1: suspend power indication
AMT_LED2: Intel® AMT indication
4.1.3 Rear Panel Connectors
Table 4-2 lists the rear panel connectors on the KINO-9652. Detailed descriptions of these
connectors can be found in Section 4.2.17.
Connector Type Label
Audio Jacks Audio connector AUDIO_CV1
CRT connector 15-pin female connector VGA1_COM1
Ethernet connector (1) RJ-45 connector LAN1_USB1
Ethernet connector (2) RJ-45 connector LAN2_USB2
Keyboard/Mouse connector 6-pin mini din connector KB_MS1
Serial port connector DB-9 male connector VGA1_COM1
Serial port connectors DB-9 male connector COM_C1
USB 2.0 port (1) USB port connector LAN1_USB1
USB 2.0 port (2) USB port connector LAN2_USB2
Table 4-2: Rear Panel Connectors
