KINO-9652 Mini-ITX SBC
Page 18
7.1 channel high definition audio
8 channels at 192 KHz/32-bit quality
Dual channel audio
Automatic jack retasking
2.6.3 Intel
®
ICH8ME Ethernet Controller
The Intel® ICH8ME integrated GbE controller is interfaced to an Intel® 82566MM Gigabit
LAN connect device through the Gigabit LAN Connect Interface (GLCI). The GLCI is
shared with the PCIe x1 port 6. The Intel® 82566MM connects the Intel® ICH8ME
integrated GbE controller to an external RJ-45 Ethernet LAN connector to provide GbE
access.
NOTE:
To enable the Intel® ICH8ME GbE Wake-on LAN function, the
Wake-on LAN function must be enabled in the BIOS. Please refer to
Section 6.5.1 (the BIOS Menu 19menu) on page 137.
Some of the features of the Intel® ICH8ME GbE controller are listed below.
Supports multi speeds including 10 Mbps, 100 Mbps and 1000 Mbps
Can operate in full-duplex mode at all supported speeds
Can operate at half-duplex at 10 Mbps and 100 Mbps
Adheres to the IEEE 802.3x Flow Control Specification.
Configurable LED operation for customization of LED display.
64-bit address master support for system using more than 4 GB of physical
memory.
Configurable receive and transmit data FIFO, programmable in 1 KB
increments.
Intelligent interrupt generation to enhance driver performance.
Compliance with Advanced Configuration and Power Interface
Compliance with PCI Power Management standards.
