PCIE-Q350 PICMG 1.3 CPU Card
Page 96
Quantity Type
1 Dual RS-232 cable
1 KB/MS cable with mini DIN
1 PS/2 Y-cable
6 SATA drive cables
3 SATA drive power cables
1 USB cable
Table 5-3: IEI Provided Cables
Separately purchased optional IEI items that can be installed are listed below:
Audio kit
TPM Module
For more details about the items listed above, please refer to Chapter 3. Installation of the
accessories listed above are described in detail below.
5.7.2 Audio Kit Installation
An optional audio kit that is separately ordered connects to the 9-pin audio connector on
the PCIE-Q350. The audio kit consists of five audio jacks. One audio jack, Mic In,
connects to a microphone. The remaining four audio jacks, Front-In, Front-Out, Rear-Out
and subwoofer connect to four speakers including a subwoofer. To install the audio kit,
please refer to the steps below:
Step 1: Locate the audio connector. The location of the 10-pin audio connector is
shown in Chapter 3.
Step 2: Align pin 1. Align pin 1 on the onboard connector with pin 1 on the audio kit
connector. Pin 1 on the audio kit connector is indicated with a white dot. See
Figure 5-11.
