C HAPTER 1 M AINTENANCE T ESTS
34 9650-0801-01 Rev. B
17.0 IBP Test
Tools Needed IBP Simulator (with accuracy better than +/- 1 mmHg), or equivalent
Setup Connect the test cables to IBP patient simulator.
Do This... Observe This... Pass/Fail
17.1 Connect the IBP patient simulator to the
Propaq MD P1 channel.
17.2 Set the IBP patient simulator to 0 mmHg.
17.3 On the Propaq MD unit, press > IBP.
17.4 On the Propaq MD unit, Press > P1->0<-. Display of 0/0(+/-2) in the P1 box
at the bottom of the display (P1 is
zeroed).
The waveform for channel 1 is
present.
o o
o o
17.5 Exit the menu to see the waveform.
17.6 Set the IBP patient simulator to 200
mmHg (or as close to 200 mmHg as your
simulator allows).
Display of 200/200(+/-5) in the P1
box at the bottom of the display as
xxx/yyy where yyy=diastolic (P1
diastolic pressure is 200 (+/-5)). o o
17.7 Connect the IBP patient simulator to the
Propaq MD P2 channel.
17.8 Set the IBP patient simulator to 0 mmHg.
17.9 On the Propaq MD unit, press > IBP.
17.10 On the Propaq MD unit, Press > P2->0<-. Display of 0/0(+/-2) in the P2 box
at the bottom of the display (P1 is
zeroed).
The waveform for channel 2 is
present.
o o
o o
17.11 Exit the menu to see the waveform.
17.12 Set the IBP patient simulator to 200
mmHg (or as close to 200 mmHg as your
simulator allows).
Display of 200/200(+/-5) in the P2
box at the bottom of the display as
xxx/yyy where yyy=diastolic (P2
diastolic pressure is 200 (+/-5)). o o
17.13 Connect the IBP patient simulator to the
Propaq MD P3 channel.
17.14 Set the IBP patient simulator to 0 mmHg.
17.15 On the Propaq MD unit, press > IBP.
